Using the System Setup Program and UEFI Boot Manager 67
Power Management Screen
Option Description
Power Management Options are OS Control, Active Power Controller,
Custom, or Maximum Performance. For all but the
Custom setting, the BIOS pre-configures the power
settings on this screen as follows:
OS Control sets the CPU power to OS DBPM, the fan
power to Minimum Power, and the memory power to
Maximum Performance. In this setting, all processor
performance information is passed from the system BIOS
to the operating system for control. The operating system
sets the processor performance based on processor
utilization.
Active Power Controller sets the CPU power to System
DBPM, the fan power to Minimum Power, and the
memory power to Maximum Performance. In this
setting, processor performance is controlled by the system
BIOS.
Maximum Performance sets all fields to Maximum
Performance.
If you select Custom, you can configure each option
independently.
CPU Power and
Performance
Management
Options are OS DBPM, System DBPM, Maximum
Performance, or Minimum Power
Fan Power and
Performance
Management
Options are Maximum Performance and Minimum
Power.
Memory Power and
Performance
Management
Options are Maximum Performance, a specified
frequency, or Minimum Power.
book.book Page 67 Tuesday, September 15, 2009 10:08 AM

Dell PowerEdge T610 Specifications

General

Form Factor	5U Tower
Chipset	Intel 5520
Memory Slots	12 DIMM slots
Processor	Up to two Intel Xeon 5500 or 5600 series processors
Memory	1GB/2GB/4GB/8GB/16GB DDR3
Drive Bays	Up to 8 x 3.5" or 16 x 2.5" hot-swap SAS, SATA or SSD
RAID Controller	PERC 6/i, PERC H700, PERC H800
Power Supply	570W or 870W
Network Interface	Embedded Broadcom NetXtreme II 5709c Gigabit Ethernet
Maximum Internal Storage	Up to 16TB
Expansion Slots	6 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
