Dell PowerEdge T610 User Manual

150 Installing System Components
• SAS backplane cable from BP_PWR connector
• Internal SD module cable from the J_SDCARD connector
• Internal USB module cable from the INT_USB connector
15 Carefully route any loose cables away from the edges of the system board.
16 Remove the system board from the chassis:
a Pull and hold the blue system board release pin. See Figure 3-27.
b While holding the release pin, slide the system board towards the
front of the system. See Figure 3-27.
WARNING: Do not lift the system board by the memory modules latches or any
component on the system board.
c
Grip the system board by the two blue touch points, located near the
two processor sockets (only one touch point is visible in Figure 3-27).
d Lift the system board up slightly to remove the system board securing
slots from the metal hooks in the chassis.
e Lift the connector end of the system board up at an angle, and lift the
system board out of the chassis. See Figure 3-27.
book.book Page 150 Tuesday, September 15, 2009 10:08 AM

Dell PowerEdge T610 Specifications

General

Form Factor	5U Tower
Chipset	Intel 5520
Memory Slots	12 DIMM slots
Processor	Up to two Intel Xeon 5500 or 5600 series processors
Memory	1GB/2GB/4GB/8GB/16GB DDR3
Drive Bays	Up to 8 x 3.5" or 16 x 2.5" hot-swap SAS, SATA or SSD
RAID Controller	PERC 6/i, PERC H700, PERC H800
Power Supply	570W or 870W
Network Interface	Embedded Broadcom NetXtreme II 5709c Gigabit Ethernet
Maximum Internal Storage	Up to 16TB
Expansion Slots	6 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
