Jumpers and Connectors 187
11
Reconnect your system and peripherals to their electrical outlets, and turn
on the system.
The existing passwords are not disabled (erased) until the system boots
with the password jumper plug removed. However, before you assign a new
system and/or setup password, you must reset the jumper plug to the
enabled position.
NOTE: If you assign a new system and/or setup password with the jumper plug
still in the disabled position, the system disables the new password(s) the next
time it boots.
12
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
13
Open the system. See "Opening the System."
14
Remove the expansion card stabilizer. See "Removing the Expansion Card
Stabilizer."
15
Move the PWRD_EN jumper plug to the enabled position (pins 2 and 4).
16
Replace the expansion-card stabilizer bracket:
Fit the slots on the bracket over the metal guides in the chassis, and slide
the bracket downwards until the release latch locks into place. See
Figure 3-27.
17
Replace the integrated storage controller card. See "Installing an
Integrated Storage Controller Card."
18
Replace the expansion card stabilizer. See "Installing the Expansion Card
Stabilizer."
19
Close the system. See "Closing the System."
20
Reconnect your system and peripherals to their electrical outlets, and turn
on the system.
21
Assign a new system and/or setup password.
To assign a new password using the System Setup program, see "Assigning
a System Password."
book.book Page 187 Tuesday, September 15, 2009 10:08 AM
