Dell PowerEdge T610 User Manual

60 Using the System Setup Program and UEFI Boot Manager
SATA Settings Displays a screen to enable or disable the integrated
SATA controller and ports. See "SATA Settings Screen."
Boot Settings Displays a screen to specify the boot mode (BIOS or
UEFI). For BIOS mode, you can also specify the boot
devices. See "Boot Settings Screen."
Integrated Devices Displays a screen to enable or disable integrated device
controllers and ports, and to specify related features and
options. See "Integrated Devices Screen."
PCI IRQ Assignment Displays a screen to change the IRQ assigned to each of
the integrated devices on the PCI bus, and any installed
expansion card that requires an IRQ. See "PCI IRQ
Assignments Screen."
Serial Communication Displays a screen to enable or disable the serial ports and
specify related features and options. See "Serial
Communication Screen."
Embedded Server
Management
Displays a screen to configure the front-panel LCD
options and to set a user-defined LCD string. See
"Embedded Server Management Screen."
Power Management Enables you to manage power usage of the processor(s),
fans, and memory modules with preconfigured or
customized settings. See "Power Management Screen."
System Security Displays a screen to configure the system password and
setup password features. See "System Security Screen,"
Using the System Password," and "Using the Setup
Password" for more information.
Keyboard NumLock
(
On default)
Determines whether your system starts up with the
NumLock mode activated on 101- or 102-key keyboards
(does not apply to 84-key keyboards).
Report Keyboard Errors
(
Report default)
Enables or disables reporting of keyboard errors during
the POST. Select Report for host systems that have
keyboards attached. Select Do Not Report to suppress all
error messages relating to the keyboard or keyboard
controller during POST. This setting does not affect the
operation of the keyboard itself if a keyboard is attached
to the system.
Option Description
book.book Page 60 Tuesday, September 15, 2009 10:08 AM

Dell PowerEdge T610 Specifications

General

Form Factor	5U Tower
Chipset	Intel 5520
Memory Slots	12 DIMM slots
Processor	Up to two Intel Xeon 5500 or 5600 series processors
Memory	1GB/2GB/4GB/8GB/16GB DDR3
Drive Bays	Up to 8 x 3.5" or 16 x 2.5" hot-swap SAS, SATA or SSD
RAID Controller	PERC 6/i, PERC H700, PERC H800
Power Supply	570W or 870W
Network Interface	Embedded Broadcom NetXtreme II 5709c Gigabit Ethernet
Maximum Internal Storage	Up to 16TB
Expansion Slots	6 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
