Dell PowerEdge T710 Technical Guide

Dell
PowerEdge T710 Technical Guide 38
11 PCI Slots
11.1 Overview
The T710 comes standard with six PCIe (gen 2) expansion slots on the motherboard. A separate
dedicated slot is provided on the motherboard for the hard drive controller. All PCIe slots are x8
connectors, except for one x16 slot.
For more information on slot specifications, see the Expansion Cards section in the Installing System
Components chapter of the Dell PowerEdge T710 Systems Hardware Owner’s Manual on
Support.Dell.com.
11.2 Express Card Specifications
The PowerEdgeT710 supports x16 cards that meet the following requirements:
 Support for full bandwidth of x16 Gen2 link
 No support for hot-plug or hot-removal
 Maximum power of 25W
 A card must only occupy the space of one slot; cards that occupy the space of two slots are
not supported
 A card is limited to 25W initial start-up power until it is configured as a high-power device; if
no value is set for the Slot Power Limit, the card is limited to 25W, and the card must then
either scale down to 25W or disable operation
 The x16 card must be able to support a maximum operating temperature of 55°C; the T710
provides a minimum transverse air velocity of ―x‖ LFM (linear feet per minute) to the x16
card
11.3 Quantities and Priorities
Refer to the Expansion Cards and Expansion-Card Risers section in the Installing System Components
chapter of the Dell PowerEdge T710 Systems Hardware Owner’s Manual on Support.Dell.com.
11.4 PCI Card Dimensions
For information about PCIe slots and card dimensions, see the Expansion Cards and Expansion-Card
Risers section in the Installing System Components chapter in the Dell PowerEdge T710 Systems
Hardware Owner’s Manual on Support.Dell.com.

Dell PowerEdge T710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	18x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	192 GB
Memory layout (slots x size)	2 x 2 GB
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	8
PCI Express x8 slots	5
Power supply	1100 W
Number of power supply units	-
Compatible operating systems	Windows Small Business Server 2011 Windows Small Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V) Windows Server 2008 R2 SP1, x64 (includes Hyper-V v2) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Tower (5U)
Processor ARK ID	37096

Weight and Dimensions

Depth	731.8 mm
Width	217.9 mm
Height	466.3 mm
Weight	35300 g
