Dell PowerEdge T710 Technical Guide

Dell
PowerEdge T710 Technical Guide 43
12.6.1 PERC H200
The H200 SAS HBA is an expansion card that incorporates two four-channel 6 Gb/s SAS IOCs for
connection to SAS hard disk drives.
12.6.2 PERC H700
The PERC H700 card has its own processor with a PCI Express Gen2 host interface and DDR2 memory
and installs into the dedicated internal storage slot. A battery is also available for backup. It
supports the internal 6 Gb/s backplane interface for internal storage options (SAS, SATA, or SSD HDD).
The PowerEdge T610 supports both 512MB and 1GB cache options on the internal H700.
12.6.3 SAS 6/iR
The integrated SAS 6/iR HBA is a half-length expansion card that plugs into a dedicated PCIe x8
storage slot (only wired for x4). It incorporates two four-channel SAS IOCs for connection to
SAS/SATA hard disk drives. It is designed in a form factor that will allow the same card to be used in
the R710, R610 and T710 platforms. SAS 6/iR is only supported when the 3.5‖ x8 backplane is
present.
12.6.4 PERC 6/i
The PERC 6/i is a half-length PCIe x8 expansion card that uses the LSI 1078 ROC (RAID on Chip)
processor with a PCI Express host interface and 256MB cache. A battery is also available for backup.
12.7 Storage Card Support Matrix
Storage Card Support Matrix Table 17.
Product
Usage
T710 Support
Slot
PCI
Con
PCI
Bracket
IO Con
RAID
Battery
Backup
PERC
SAS/
SATA
PERC 6/i
Integrated
Internal
backplane
storage
(HDD, SSD)
Yes—Max 1
Storage
slot
x8
No
x4 int.
0, 1, 5,
6, 10,
50, 60
Yes
PERC 6/E
Adapter
External
SAS/SATA
storage
Yes—Max 2
(MD1000 and
MD1020)
PCIe slot
x8
Yes
x4 ext.
x4 ext.
0, 1, 5,
6, 10,
50, 60
Yes
PERC 5/E
Adapter
External
legacy
storage
Yes—Max 2
(MD1000 only)
PCIe slot
x8
Yes
x4 ext.
x4 ext.
0, 1, 5,
10, 50
Yes
SAS
HBA
SAS/
SATA
SAS 6/iR
Integrated
Internal
backplane
storage
(No tape or
SSD support)
Yes—Max 1
Storage
slot
x8
No
x4 int.
x4 int.
0, 1
No
SAS 5/iR
Adapter
Internal SAS
tape
Yes—Max 1
PCIe slot
x8
Yes
x4 int.
—
No

Dell PowerEdge T710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	18x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	192 GB
Memory layout (slots x size)	2 x 2 GB
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	8
PCI Express x8 slots	5
Power supply	1100 W
Number of power supply units	-
Compatible operating systems	Windows Small Business Server 2011 Windows Small Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V) Windows Server 2008 R2 SP1, x64 (includes Hyper-V v2) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Tower (5U)
Processor ARK ID	37096

Weight and Dimensions

Depth	731.8 mm
Width	217.9 mm
Height	466.3 mm
Weight	35300 g
