Dell PowerEdge T710 Technical Guide

Dell
PowerEdge T710 Technical Guide 44
Product
Usage
T710 Support
Slot
PCI
Con
PCI
Bracket
IO Con
RAID
Battery
Backup
ICH
SATA
On planar
via
chipset
Internal SATA
optical
and/or tape
(no hard
drive)
Yes—2 ports for
optical and/or
tape
—
—
—
x1 int.
—
—
LSI
2032
SCSI
LSI 2032
Adapter
Internal/
External SCSI
tape or
external
legacy SCSI
storage
Yes—Max 2
PCIe slot
x4
Yes
SCSI
int.
SCSI
ext.
—
—
12.8 Optical Drives
SATA optical drives are optional and connect to the planar via a SATA interface. IDE optical drives
are no longer supported. The following optical drives are available on T710:
 DVD-ROM
 DVD+RW
If the optical drive is not ordered with the system, a blank is installed in its place. In the absence of
tape drive, an optional second SATA optical drive is installed in the bay adjacent to the first optical
drive.
12.9 Tape Drives
Tape drives are optional and connect to the planar via SATA/SCSI controller card/SAS controller card.
IDE tape drives are no longer supported. The following tape drives are available for use on the T710:
 Internal SATA, SCSI, and SAS
 External SCSI and SAS
If the tape drive is not ordered with the system, a blank is installed in its place.
T710 supports a number of internal tape backup options. Only half-height backup options are
supported.

Dell PowerEdge T710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	18x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	192 GB
Memory layout (slots x size)	2 x 2 GB
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	8
PCI Express x8 slots	5
Power supply	1100 W
Number of power supply units	-
Compatible operating systems	Windows Small Business Server 2011 Windows Small Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V) Windows Server 2008 R2 SP1, x64 (includes Hyper-V v2) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Tower (5U)
Processor ARK ID	37096

Weight and Dimensions

Depth	731.8 mm
Width	217.9 mm
Height	466.3 mm
Weight	35300 g
