Dell PowerEdge T710 Technical Guide

Dell
PowerEdge T710 Technical Guide 51
16.3 Embedded Server Management
The PowerEdge T710 implements circuitry for the next generation of Embedded Server Management.
It is Intelligent Platform Management Interface (IPMI) v2.0 compliant. The iDRAC (Integrated Dell
Remote Access Controller) is responsible for acting as an interface between the host system and its
management software and the periphery devices.
iDRAC6 provides features for managing the server remotely or in data center lights-out
environments.
Advanced iDRAC features require the installation of the optional iDRAC6 Enterprise card.
16.4 Dell Lifecycle Controller and Unified Server Configurator
Embedded management is comprised of interdependent pieces:
• Dell Lifecycle Controller
• Unified Server Configurator
• iDRAC6
Dell Lifecycle Controller powers the embedded management features. It includes integrated and
tamper-proof storage for system-management tools and enablement utilities (firmware, drivers,
etc.). Lifecycle Controller enables pre-OS server deployment, OS installation, platform updates,
platform configuration, and diagnostics capabilities.
Dell Unified Server Configurator (USC) is a graphical user interface (GUI) that aids in local server
provisioning in a pre-OS environment. To access the Unified Server Configurator, press the <F10> key
within 10 seconds of the Dell logo appearance during the system boot process. Table 21 details the
current functionality enabled by the USC.
Unified Server Configurator Features and Description Table 21.
Feature
Description
Faster O/S Installation
Drivers and the installation utility are embedded on system, so no
need to scour Dell.com.
Faster System Updates
Integration with Dell support automatically directed to latest
versions of the Unified Server Configurator, iDRAC, RAID, BIOS, NIC,
and power supply.
Update Rollback
Ability to recover to previous ―known good state‖ for all updatable
components.
More Comprehensive Diagnostics
Diagnostic utilities are embedded on system.
Simplified Hardware Configuration
Detects RAID controller and allows user to configure virtual disk and
choose virtual disk as boot device, eliminating the need to launch a
separate utility. Also provides configuration for iDRAC, BIOS, and
NIC/LOM.
16.5 Integrated Dell Remote Access Controller
The integrated Dell Remote Access Controller (iDRAC6) provides IT Administrators comprehensive yet
straightforward management of remote servers, by delivering ―as if you are there‖ presence and
control. iDRAC6 helps users to save time and money by eliminating travel to the remote server(s),
whether that server is located in a different room, a different building, a different city, or in a

Dell PowerEdge T710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF8
Processor cache	4 MB
Processor cores	4
Processor model	E5506
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	18x DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	192 GB
Memory layout (slots x size)	2 x 2 GB
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	8
PCI Express x8 slots	5
Power supply	1100 W
Number of power supply units	-
Compatible operating systems	Windows Small Business Server 2011 Windows Small Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 includes Hyper-V) Windows Server 2008 R2 SP1, x64 (includes Hyper-V v2) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Tower (5U)
Processor ARK ID	37096

Weight and Dimensions

Depth	731.8 mm
Width	217.9 mm
Height	466.3 mm
Weight	35300 g
