19
FIGURE 19
OPERATION
CUTTING WARPED MATERIAL
face should be against the fence as shown in Figure 17.
X
1
2
3
4
5
6
7
CLAMPING WIDE WORKPIECES
When cutting wide work pieces, such as 2 in. x 6 in.,
clamp the workpiece to the work table using a C-clamp
as shown in Figure 19.
Keep clamps away from the path of
the blade and blade guard assembly.
Figure 18. It will pinch the blade near the completion of
the cut.
To avoid a kickback and to avoid
serious personal injury, never position
the concave edge of bowed or warped material against
the fence.
FIGURE 18FIGURE 17
