3.2.1 LCD 顯示面板與按鍵
3.2.2 逆變器輸入與輸出介面
圖3-3 : 顯示面板與按鍵
圖3-4 : 輸入與輸出介面
Dry
contact
AC
connector
DC
connector
Communication
RS-485
DC switch
DC SWITCH只在-120系列機種才有提供;-020系列機種沒有提供。
說 明
120
產品概觀
