3 产品概观
3.1 尺寸规格
3.2 功能介绍
逆变器外部对象如图3-2所示，在3.2.1至3.2.2章节中有详细功能介绍。
475.3
414.3
155
Label
Grounding
(Noted : Delta recommend the grounding of the inverter housing)
Dry
contact
AC
connector
DC
connector
Comm.
connector
DC switch
图3-1 : 尺寸规格
图3-2 : 逆变器外观
65
产品概观
