5.3 DC Connection (from PV Array)
The maximum open circuit voltage of the PV Array must not exceed 600Vdc.
The maximum recommended input power to the inverter is:
*with unbalanced input power
CAUTION !
WARNING !
• When undertaking DC wiring, please ensure the correct polarities are
connected.
• When undertaking DC wiring please ensures that the DC isolator switch
on the PV array is OFF.
RPI H3AType of limit RPI H4A RPI H5A
Total input power 3200W 5280W4320W
Per MPP tracker* 3200W 3500W3200W
RPI H3A
MPP range with Max. power
RPI H4A RPI H5A
Symmetrical load
160~500V 220~500V180~500V
Asymmetrical load
320~500V 291~500V266~500V
Max. ratio for asymmetrical load 100/0%;0/100% 70/30%;30/70%80/20%;20/80%
The device installed between the PV Array and inverter must meet the rating
of voltage higher than this device’s maximum input voltage.
NOTE
5.3.1 Asymmetrical Loading
The inverters operate using two separate MPP trackers that can handle both symmetrical
and asymmetrical loads to allow for optimum adjustment. This allows for the requirements
of complex PV system designs to be fulfilled. For example: east/west-facing roof
(symmetrical load) or a south facing roof such as a dormer (asymmetrical load).
