16
Amplon N Series
No. Icon Description
8 V Means ‘voltage’.
9
Means ‘percentage’.
10 Hz Means ‘frequency’.
11 kVA Means ‘kVA’.
12 kW Means ‘kW’.
13 MIN Means ‘minute’.
14
Means the UPS’s internal temperature.
3.5 Flow Chart of the 7-Segment Display
The following ow chart helps you to understand how to go through each display
screen. Here, we take ‘Standby Mode’ as an example. Each of the display diagrams
shown in below is for reference only. Actual display depends on the operation of the
UPS.
After this screen appears around 10
seconds, the scrolling function will be
active. The scrolling button is .
To Next Page
