Delta VFD-ED Series User Manual

Chapter 6 Optional Accessories | VFD-ED
6-2
The optional accessories listed in this chapter are available upon request. Installing additional
accessories to your drive can substantially improve the drive’s performance. Select accessories
according to your needs or contact your local distributor for suggestions.
6-1 Brake Resistors and Brake Units Used in AC Motor Drives
Recommended Model Selection
Voltage
Delta’s
Motor Drive
Model
IM 10% ED*
1
PM 30% ED*
2
Min. Resistor
Value*
3
(Ω)
Suggested
Resistor Value*
4
(Ω)
Suggested
Braking Power
(kW)
Min. Resistor
Value (Ω)
Suggested
Resistor Value
(Ω)
Suggested
Braking Power
(kW)
230V
VFD022ED21S 38.0 70.0 0.3 38.0 50.0 1.0
VFD037ED21S 19.0 30.0 0.5 19.0 32.0 1.5
VFD040ED23S 19.0 30.0 0.5 19.0 32.0 1.5
VFD055ED23S 15.6 20.0 1.0 15.6 25.0 2.0
VFD075ED23S 11.5 20.0 1.0 11.5 16.7 3.0
VFD110ED23S 9.5 13.0 1.5 9.5 12.5 4.0
VFD150ED23S 8.3 10.0 2.0 8.3 10.0 5.0
VFD185ED23S 5.8 8.0 2.0 5.8 7.8 7.5
VFD220ED23S 5.8 6.6 3.0 5.8 6.5 9.0
VFD300ED23S 4.8 5.1 4.0 4.8 5.0 10.0
VFD370ED23S 3.2 3.9 4.8 3.2 3.6 14.0
460V
VFD040ED43S 54.3 100.0 0.5 54.3 100.0 2.0
VFD055ED43S 48.4 75.0 1.0 48.4 100.0 2.0
VFD075ED43S 39.4 75.0 1.0 39.4 60.0 3.0
VFD110ED43S 30.8 43.0 1.5 30.8 50.0 4.0
VFD150ED43S 25.0 32.0 2.0 25 39.0 6.0
VFD185ED43S 20.8 32.0 2.0 20.8 26.0 7.2
VFD220ED43S 19.0 26.0 3.0 19.0 26.0 9.0
VFD300ED43S 14.1 20.0 4.0 14.1 19.5 12.0
VFD370ED43S 12.7 14.3 4.5 13.8 15.6 15.0
VFD450ED43S 12.7 13.0 6.0 10.3 13.0 18.0
VFD550ED43S 9.5 10.2 8.0 6.9 9.8 19.2
VFD750ED43S 6.3 7.2 9.0 6.4 7.1 26.4
Table 6-1
*
1
The brake resistor should be able to endure 10 times the overload capacity.
*
2
The brake resistor should be able to endure 3.3 times the overload capacity.
*
3
If you choose other brake resistors instead of Deltas, calculate the maximum power and average power of t he
selected braking power to ensure that they meet the requirements. Maximum power: Vb
2
/R; average power:
Vb
2
/R x ED%. (Vb stands for braking voltage; R stands for brake resistor value.)
*
4
The calculation of the brake resistor value and braking power is based on Delta’s brake resistor.
