NOTE:
1. The +24V-DCM internal 24V power capacity is 60 mA. For the output capacity of other external loads, the
current consumption of the corresponding number of MI terminals should be deducted (6 mA for each MI
terminal).
2. For VFD007EL21W(-1) model, if you need to install fan kit, the fan power supply is powered by +24V-DCM.
Except for the normal use of the MI terminal, do not use other external loads in the same time to prevent the
+24V terminal from being overloaded and the drive damaged.
