Group 10: PID Control Parameters
Parameters Explanation Settings
Factory
Setting
00: Inhibit PID operation
01: Input negative PID feedback from
external terminal (AVI) 0 to +10V
02: Input negative PID feedback from
external terminal (ACI) 4 to 20mA
03: Input positive PID feedback from
external terminal (AVI) 0 to +10V
10-00
Input terminal for PID
Feedback
04: Input positive PID feedback from
external terminal (ACI) 4 to 20mA
00
10-01
Gain over PID Detection
value
0.00 to 10.00 1.00
10-02 Proportional Gain (P)
0.0 to 10.0
1.0
10-03 Integral Gain (I)
0.00 to 100.00 sec (0.00 disable)
1.00
10-04 Derivative Control (D)
0.00 to 1.00 sec
0.00
10-05
Upper Bound for Integral
Control
00 to 100% 100
10-06 Primary Delay Filter time 0.0 to 2.5 sec 0.0
10-07 PID Output Freq Limit 0 to 110% 100
10-08
Feedback Signal Detection
time
0.0 to 3600.0 sec 60.0
00: Warn and keep operation
01: Warn and RAMP to stop
10-09
Treatment of the
Erroneous Feedback
Signals
02: Warn and COAST to stop
00
10-10 PG Pulse Range 01 to 40000 600
00: Disable PG
01: Single phase
02: Forward / Counterclockwise rotation
10-11 PG Input
03: Reverse / Clockwise rotation
00
10-12
Proportional Speed control
(P)
0.0 to 10.0 1.0
10-13 Integral Speed Control (I) 0.00 to 100.00 (0.00 disable) 1.00
10-14
Speed Control Output
Frequency Limit
0.00 to 10.00 Hz 10.00
10-15
Sample time for refreshing
the content of 210DH and
210EH
0.01~1.00 seconds 0.10
10-16
Deviation Range of PID
Feedback Signal Error
0.00~100.00% 100.00
