5-2
00 - 03
Start-up Display Page Selection
a
Factory Setting: 00
Settings 00 Display the Master Frequency (F)
01 Display the actual operation frequency (H)
02 Display the content of user-defined unit (U)
03 Multifunction display, [default setting: output current (A)]
04 FWD/REV command
 This setting determines the display mode after power is applied to the drive.
00 - 04
Content of Multi Function Display
a
Factory Setting: 00
Settings 00 Display the output current (A)
01 Display the counter value (C)
02 Display the content of PLC time (1.tt)
03 Display the DC BUS voltage (U)
04 Display the output voltage (E)
05 Display the power factor angle (n.)
06 Display the output power (P), unit: kW
07 Display actual motor speed (enable during vector control or Pulse
Generator feedback control) (HU)
08 Display the estimative value of the ration of torque (t)
09 Display PG numbers/10ms (G)
10 Display analog feedback signal value (b)
11 Display AVI (U1.) (%)
12 Display ACI (U2.) (%)
13 Display AUI (U3.) (%)
 This parameter determines the content for Multi function Display. User also can view
other information by pressing the “LEFT” key on the VFD-PU01 when the display page is
at Multi function Display.
 The 100% of settings 11-13 is +10V or 20mA.
00 - 05
User Defined Coefficient K
a
Factory Setting: 1.00
Settings 0.01 to d 160.00 Unit: 0.01
 The coefficient K determines the multiplying factor for the user-defined unit.
The display value is calculated as follows:
U (user-defined unit) = Frequency Command x K (Pr.00-05)
H (actual output) = (actual output frequency) x K (Pr.00-05)
