VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
C-8
VFD300B43A 30.0 kW (40HP) 460V / 3-phase
VFD370B43A 37.0 kW (50HP) 460V / 3-phase
VFD450B43A 45.0 kW (60HP) 460V / 3-phase
Unit: mm (inches)
335.0 [13.19]
370.0 [14.57] 260.0 [10.24]
589.0 [23.19]
560.0 [22.05]
18.0 [0.71]
132.5 [5.22]
R6.5[0.25]
13.0[0.51]
21.0[0.83]
