Basic Operation Basic Operation
ENGLISH
Auto tuner presets
Listening to the radio
Auto preset memory
Hold the PRESET • button and press the POWER
switch on the main unit.
• The unit automatically begins searching for FM broadcast
stations.
When the first FM broadcast station is found, that station is
stored in the preset memory at channel A1.
Subsequent stations are automatically stored in order at
preset channels A1 to A8, B1 to B8, C1 to C8, D1 to D8, E1
to E8, F1 to F8 and G1 to G8 for a maximum of 56 stations.
Channel A1 is tuned in after the auto preset memory
operation is completed.
• This unit is equipped with a function for automatically searching
for FM broadcast stations and storing them in the preset
memory.
• The “Auto tuner preset” operation can also be performed at
“System setup” ( page 42).
• If an FM station cannot be preset automatically due to poor
reception, use the “Manual tuning” operation to tune in the
station, then preset it using the manual “Preset memory”
operation.
•To interrupt this function, press the ON/STANDBY switch.
2 DEFAULT SETTINGS
A1 ~ A8
87.5 / 89.1 / 98.1 / 107.9 / 90.1 / 90.1 /
90.1 / 90.1 MHz
B1 ~ B8
520 / 600 / 1000 / 1400 / 1500 / 1710 kHz,
90.1 / 90.1 MHz
C1 ~ C8 90.1 MHz
D1 ~ D8 90.1 MHz
E1 ~ E8 90.1 MHz
F1 ~ F8 90.1 MHz
G1 ~ G8 90.1 MHz
•When in the auto tuning mode on the FM band, the “STEREO”
indicator lights on the display when a stereo broadcast is tuned
in. At open frequencies, the noise is muted and the “TUNED”
and “STEREO” indicators turn off.
1
Set the input source to “TUNER”.
(Main unit) (Remote control unit)
2
Watching the display, press the BAND button to
select the desired band (AM or FM).
3
Press the MODE button to set the auto tuning
mode.
4
Press the TUNING (+) or (–) button.
Automatic searching begins, then stops when a station is
tuned in.
Auto tuning
To Next Page
