Advanced Operation Advanced Operation
39
ENGLISH
ENGLISH
Multi zone music entertainment system
•When the outputs of the ZONE2 OUT terminals are wired and
connected to integrated amplifiers installed in other rooms, different
sources can be played in rooms other than the MAIN ZONE in which
this unit and the playback devices are installed. (Refer to ZONE2 of
the diagram the right.)
•ZONE2 speaker out and pre-out can be used when “ZONE2” is
selected at “Power Amp Assignment” in the “System Setup” menu.
In this case, surround back speaker out cannot be used for MAIN
ZONE.
• When a sold separately room-to-room remote control unit (DENON
RC-616, 617 or 618) is wired and connected between the MAIN
ZONE and ZONE2, the remote-controllable devices in the MAIN
ZONE can be controlled from ZONE2 using the remote control unit.
• For the AUDIO outputs, use high quality pin-plug cables and wire in
such a way that there is no humming or noise.
• For instructions on installation and operation of separately sold devices,
refer to the devices’ operating instructions.
• When the main unit is set to the recording output mode, ZONE2
remote control button cannot be operated.
¢ When using the SURR.BACK/ZONE2 amplifier as the SURROUND BACK
• 7.1-channel playback using the surround back speaker is possible in the MAIN ZONE.
•To use the ZONE2 line output, turn on ZONE2.
• The ZONE2 OUT terminal’s output level cannot be adjusted with the remote control unit.
[System configuration and connections example]
Using external amplifier.
To Next Page
