Denon AVR-1911 User Manual

40
ENGLISH
Quick select function
It is also possible to save three settings for ZONE2.
n Saving the settings
1
Set the items below to the settings
you want to save.
q Input source (vpage39)
w Volume (vpage39)
2
Switch ZONE SELECT to
“ZONE2”.
The remote control unit switches to the
operating mode for ZONE2.
3
Press and hold the desired QUICK SELECT button until
“Memory” appears on the display.
The current settings will be memorized.
GQuick select defaultsH
Input Source Volume
QUICK SELECT 1 BD –40dB
QUICK SELECT 2 SAT/CBL –40dB
QUICK SELECT 3 DOCK –40dB
n Recalling the settings
1
Switch ZONE SELECT to
“ZONE2”.
The remote control unit switches to the
operating mode for ZONE2.
2
Press QUICK SELECT at which the
settings you want to call out are
saved.
Naming quick select settings
See “Quick Select Name” (vpage59).

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
