Denon AVR-1913 Service Manual

195
MAIN PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC4000 00D2630553006 IC NJM7805FA J126780500130S
IC4001 00D2630554005 IC NJM7905FA J126790500020S
IC4002 00D2630810008 IC NJM7808FA J126780800030S
IC4003 00D2630553006 IC NJM7805FA J126780500130S
IC4004 00D2630503001 IC NJM7908FA J126790800020S
z
IC4140 231010091708S IC TOP258MG G200258000010S
z
IC4142 00D2623047008 IC PC123X2YFZ (DIP4P SHARP) K614123000010S
IC4143 212050010508S IC KIA2431AP J126243118010S
Q4000-4004 943215500020S TR 2SA RT1P141C J520101411210S
Q4005-4009 943216500020S TR 2SC RT1N141C J522101411210S
Q4016 943214500030S TR 2SC INC2001AC1 J522020011210S
D4000-4004 963201500170D D,SWITCHING CHIP LBAS16HT1G K005041480230S
D4007 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4008 963203500300D D,RECTIFIER BRIDGE DIODE K047100600220S
D4013 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4014,4015 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4016 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4017,4018 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4019 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4020-4022 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4023 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4024,4025 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4026 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4027-4030 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4031,4032 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4033-4036 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4037 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4038 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4039 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4140-4148 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4149 963204500210D D,SCHOTTKY S30SC6MT 60V 30A K120300600010S
D4150 00D2760401905 D,SWITCHING 1SS133T K000013300520S
ZD4000,4001 963202500360D D,ZENER ZJ33B-0.5W/5MA-52MM K06033R044522S
ZD4002 963202500330D D,ZENER ZJ6.8B-0.5W/5MA-52MM K06006R844522S
ZD4147-4149 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM 1913E3, 2113CIE3 K06039R044522S
ZD4150-4157 963202500350D D,ZENER ZJ22B-0.5W/5MA-52MM K06022R044522S
ZD4158 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM K06039R044522S
ZD4159 963202500320D D,ZENER ZJ5.6B-0.5W/5MA-52MM K06005R644522S
ZD4160 00D2760760963 ZENER DIODE MTZJ6.2B-0.5W 1913E3, 2113CIE3 K06006R244520S
ZD4160 00D2760665903 ZENER DIODE MTZJ16B-0.5W 2113E2, 2113E1C K06016R044520S
RESISTORS GROUP
R4000,4001 963125010110S R,METAL FILM 470-J,2W C060047166060S
R4002-4015 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4025-4027 963125500070D R,METAL FILM 100PPM 1.1K-J C060011265050S

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
