Denon AVR-1913 Service Manual

206
HDMI PCB UNIT ASS'Y
NOTE: When replacing the U3002 or U1602, use the U3002(943243100930S) or U1602(963248100710S).
When the following are replaced, always rewrite with updated rmware using DFW.
(Refer to "PROCEDURE FOR UPGRADING THE VERSION OF THE FIRMWARE" (52 page).)
• HDMI PCB UNIT ASS'Y
• U1602 (MX25L6406EM2I-12G)
• U2205 (EPM3032A-TC44)
• U3002 (R5F56108VNFP)
• U2003 (MX29LV160DBTI-70G)
d
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q1001-1004 943216500020S TR 2SC RT1N141C J522101411210S
Q1005-1008 943216500050S TR 2SC RT1N441C J522104411210S
Q1303-1305 943216500020S TR 2SC RT1N141C J522101411210S
Q1606 963223500020D SEMI,FET CHIP UPA672T-T1-A SC-70 J543672001010S
Q2201 943216500050S TR 2SC RT1N441C J522104411210S
Q2202 943216500020S TR 2SC RT1N141C J522101411210S
Q3001 943214500020S TR 2SC 2SC3052 2113CIE3 J522305200050S
Q3002 943215500030S TR 2SA RT1P441C 2113CIE3 J520104411210S
Q3201 943214500020S TR 2SC 2SC3052 J522305200050S
Q3202 963219002180S TR 2SD2114KT146W J5232114K0010S
Q3203 943214500020S TR 2SC 2SC3052 J522305200050S
Q3204 963212500030S TR 2SA ISA1530AC1 J520015301210S
Q3205,3206 943214500020S TR 2SC 2SC3052 J522305200050S
Q3207 963212500030S TR 2SA ISA1530AC1 J520015301210S
Q3208 943214500020S TR 2SC 2SC3052 J522305200050S
Q3209 943216500020S TR 2SC RT1N141C J522101411210S
Q3210 943214500020S TR 2SC 2SC3052 J522305200050S
Q3211 943216500020S TR 2SC RT1N141C J522101411210S
Q3212 943214500020S TR 2SC 2SC3052 J522305200050S
Q3213-3216 943216500020S TR 2SC RT1N141C J522101411210S
Q3217 943214500020S TR 2SC 2SC3052 J522305200050S
Q3218,3219 943216500020S TR 2SC RT1N141C J522101411210S
Q3220 943214500020S TR 2SC 2SC3052 J522305200050S
Q3601-3605 943216500050S TR 2SC RT1N441C J522104411210S
Q3606,3607 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U J521051401010S
Q3608-3612 963219004200S CHIP FDC608PZ P-CH J543608000010S
Q3613,3614 943216500020S TR 2SC RT1N141C J522101411210S
Q3615-3618 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U J521051401010S
Q3620 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U J521051401010S
Q3621-3624 943216500020S TR 2SC RT1N141C J522101411210S
Q3626 943216500020S TR 2SC RT1N141C J522101411210S
Q3627 943214500020S TR 2SC 2SC3052 J522305200050S
D1001 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D1313 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D2401 00D2760739907 D,SWITCHING CHIP KDS181S(B)-THICK K005018100040S
D3001 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G 2113CIE3 K125521305230S
D3002 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G 2113CIE3 K125521305230S
D3006 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G 2113CIE3 K125521305230S
D3201 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
D3401 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D3602 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
RESISTORS GROUP
R1001-1004 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R1005-1008 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1009-1012 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
