Denon AVR-1913 Service Manual

93
4. AUDIO
4.1. AUDIO CHECK
Audio output NG.
Refer to "Audio Check PATH" (101 page).
Check ANALOG audio BLOCK.
Check Digital audio BLOCK.
Check ADC BLOCK
Check HDMI BLOCK.
Check other factors.
Check HDMI BLOCK.
Check Digital audio BLOCK
CHECK1 INPUT SURROND MODE SOURCE
Audio output OK? ANALOG 2CH DIRECT ANALOG
CHECK2 INPUT SURROND MODE SOURCE
Audio output OK? COAX or OPT Don't care
Legacy
(PCM or DolbyDigital or dts…)
CHECK4 INPUT SURROND MODE SOURCE
Audio output OK? HDMI Don't care
Legacy
(PCM2ch or DolbyDigital or dts…)
CHECK6 INPUT Connect
AVR's (connected in HDMI) audio
output OK?
HDMI This unit's HDMI OUT → Other AVR's HDMI IN
Setting SURROND MODE SOURCE
CEC STANDBY Don't care HBR audio(DolbyTrueHD or dtsHD MA)
CHECK5 INPUT SURROND MODE SOURCE
Audio output OK? HDMI Don't care
HBR audio
(DolbyTrueHD or dtsHD MA)
CHECK3 INPUT SURROND MODE SOURCE
Audio output OK? ANALOG 2CH MULTICH STEREO ANALOG
YES
YES
YES
YES
YES
NO
NO
YES (Digital audio Block is OK)
NO
NO
NO
NO

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
