Denon AVR-1913 Service Manual

222
Ref. No. Part No. Part Name Remarks Q'ty New
U3608 943239100730S IC,LINEAR-RESET PST8448UR J125844800010S
nsp
BRACKET AVR2113(DENON)HDMI
FRONT
4010215496000S
RS232 PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC4701 236810090504S IC ILX3232D 2113CIE3 J046323200020S
CAPACITORS
GROUP
C4706 nsp C,CERAMIC 0.1UF-K/50V 2113CIE3 D011104577160S
C4707 00D2544573981 C,ELECT 10UF-M/50V 2113CIE3 D040100087070S
C4711,4712 nsp C,CERAMIC 0.1UF-K/50V 2113CIE3 D011104577160S
C4716,4717 nsp C,CERAMIC 0.1UF-K/50V 2113CIE3 D011104577160S
C4718,4719 nsp C,CERAMIC 33PF-J/50V 2113CIE3 D010330167160S
OTHERS PARTS GROUP
BKT4700 nsp BRACKET 0.8t/SCREW 2113CIE3 4010210196100S
CN4702 nsp CN,WAFER C125Z2-07 7P 2113CIE3 L109012520720S
CP4700 nsp CN,WAFER C125Z1-09 9P 2113CIE3 L109012510920S
CP4701 nsp CN,WAFER C125Z1-13 13P 2113CIE3 L109012511320S
CP4702 nsp CN,WAFER C125Z1-07 7P 2113CIE3 L109012510720S
J4709 nsp JUMPER (0.6/52MM) 2113CIE3 L045084006040S
JACK4702 00D2051305008 CN.WAFER 9P 2113CIE3 L103090090030S

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
