Denon AVR-1913 Service Manual

99
NO
NO
NO
Is there damage in IC4140
(TOP258MG)?
Is there the damage in D4142/D4143/
D4144/D4145/IC4140?
Repair the solder short part of the PCB
board.
Check the damage of each part.
Replace the damaged parts.
Replace the damaged parts.
Is the fuse (F4140) blown?
Is there solder short circuit in the PCB
board?
Is there a damaged part?
Replace the IC4140 (TOP258MG) and
D4142/D4143/D4144/D4145.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS

Denon AVR-1913 Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Audio formats supported	AAC, FLAC, MP3, WMA
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Card reader integrated	No
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	162 mm
Width	434.3 mm
Height	328.9 mm
Weight	9099 g
