11
DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB FRONT HDMI ASSY
(Ref. No. of EXPLODED VIEW : P1)
PCB USB ASSY
(Ref. No. of EXPLODED VIEW : P2)
PCB FRONT ASSY
(Ref. No. of EXPLODED VIEW : P3)
PCB FUNCTION ASSY
(Ref. No. of EXPLODED VIEW : P4)
PCB CNT ASSY
(Ref. No. of EXPLODED VIEW : P5)
PCB FRONT HDMI
(Ref. No. of EXPLODED VIEW : P6)
RADIATOR ASSY
Refer to "DISASSEMBLY
7. RADIATOR ASSY"
and "EXPLODED VIEW"
PCB AMP ASSY
(Ref. No. of EXPLODED VIEW : P7)
PCB GUIDE R
(Ref. No. of EXPLODED VIEW : P16)
PCB GUIDE L
(Ref. No. of EXPLODED VIEW : P17)
PCB TOP_GUIDE
(Ref. No. of EXPLODED VIEW : P18)
POWER TRANS MAIN
Refer to "DISASSEMBLY
4. POWER TRANS MAIN"
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 13)
TOP COVER
PCB HDMI
Refer to "DISASSEMBLY
3. PCB HDMI"
and "EXPLODED VIEW"
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : P13)
PCB MX PORT/PCB RS232C
(AVR-2113CIE3 only)
Refer to "DISASSEMBLY
2. PCB MX PORT/PCB RS232C"
and "EXPLODED VIEW"
PCB RS232C ASSY
(Ref. No. of EXPLODED VIEW : P14)
PCB MX PORT ASSY
(Ref. No. of EXPLODED VIEW : P15)
PCB VIDEO ASSY
Refer to "DISASSEMBLY
5. PCB VIDEO ASSY"
and "EXPLODED VIEW"
PCB MAIN ASSY
(Ref. No. of EXPLODED VIEW : P9)
PCB INPUT ASSY
(Ref. No. of EXPLODED VIEW : P10)
PCB FRONT CNT ASSY
(Ref. No. of EXPLODED VIEW : P11)
PCB VIDEO ASSY
(Ref. No. of EXPLODED VIEW : P12)
BACK CHASSIS
PCB SMPS
Refer to "DISASSEMBLY
6. PCB SMPS"
and "EXPLODED VIEW"
PCB SMPS ASSY
(Ref. No. of EXPLODED VIEW : P8)
To Next Page
