17
6. PCB SMPS
(1) Remove the screws.
(2) Disconnect the connector wire.
PCB FRONT CNT
PCB HDMI
→ →
PCB SMPS
→
TOP
COVER
BACK CHASSIS
PCB VIDEO
→ →
Proceeding :
View from the bottom
CP5003
PCB FRONT CNT
