PARTS LIST OF EXPLODED VIEW
s
z
Parts indicated by "nsp" on this table cannot be supplied.
z
PCB ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the PCB ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
1913E3 : U.S.A. & Canada model
2113CIE3 : U.S.A. & Canada model 2113E2 : Europe model 2113E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
P3A nsp FRONT PCB UNIT ASS'Y 1913BKE3 7028071851020 1
P3A nsp FRONT PCB UNIT ASS'Y 2113CIBKE3 7028071851010 1
P3A nsp FRONT PCB UNIT ASS'Y
2113BKE2,
2113SPE1C
7028071851020 1
P1 - PCB FRONT HDMI ASSY -
P2 - PCB USB ASSY -
P3 - PCB FRONT ASSY -
P4 - PCB FUNCTION ASSY -
P5 - PCB CNT ASSY -
P6 - PCB F/H_GUIDE ASSY -
P7 - PCB AMP ASSY -
P8 - PCB SMPS ASSY -
P9A nsp PCB MAIN ASSY 7028071841010 1
P9 - PCB MAIN ASSY -
P10A nsp INPUT PCB UNIT ASS'Y 1913BKE3 7028071881020 1
P10A nsp INPUT PCB UNIT ASS'Y 2113CIBKE3 7028071881010 1
P10A nsp INPUT PCB UNIT ASS'Y
2113BKE2,
2113SPE1C
7028071881020 1
P10 - PCB INPUT ASSY -
P11 - PCB FRONT CNT ASSY -
P12A nsp VIDEO PCB UNIT ASS'Y 7028071861010 1
P12 - PCB VIDEO ASSY -
P13A 8U1891002200S HDMI PCB UNIT ASS'Y 1913BKE3 7025HK1115015 1
P13A 8U1891002400S HDMI PCB UNIT ASS'Y 2113CIBKE3 7025HK1114015 1
P13A 8U1891002300S HDMI PCB UNIT ASS'Y 2113BKE2 7025HK1114025 1
P13A 8U1891003600S HDMI PCB UNIT ASS'Y 2113SPE1C 7025HK1114045 1
P13 - PCB HDMI ASSY
P14 - PCB RS232C ASSY 2113CIBKE3
P15 - PCB MX PORT ASSY 2113CIBKE3
P16 - PCB GUIDE R
P17 - PCB GUIDE L
P18 - PCB TOP_GUIDE
1 963443100510D PANEL SUB 3067215571000S 1 *
2 963412100730D KNOB VOLUME
1913BKE3,
2113CIBKE3,
2113BKE2
5080212641000S 1 *
2 963412100740D KNOB VOLUME 2113SPE1C 5087212641100S 1 *
3 963419100470D COVER RCA 4310215591000S 1 *
