Denon AVR-2113CI Service Manual

95
4.3. Analog audio
No sound is output
Is the voltage of ±7V supplied to
INPUT B'D CN4004?
Is the audio signal transmitted to
INPUT B'D CN401?
Is the serial data for electronic volume
transmitted to INPUT B'D CP4200?
Once more, check the connection of the connector.
When you can specify the troubled channel and function, check the corresponding
signal route.
The power supply of ±7V is repaired.
The power amplier is repaired.
Is the connector correctly connected
with HDMI B'D?
Connect the connectors properly.
The HDMI B'D is repaired.
YES
NO
YES
NO
NO
YES
YES
YES
