Denon AVR-2113CI Service Manual

201
FRONT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC4400,4401 00D2631289900 IC AZ4580M J121458000020S
Q4400 943216500050S TR 2SC RT1N441C J522104411210S
Q4401 943215500030S TR 2SA RT1P441C J520104411210S
Q4402,4403 943214500020S TR 2SC 2SC3052 J522305200050S
Q4404 00D9630226705 TR KTC1027Y J5021027Y0020S
Q4405 943216500020S TR 2SC RT1N141C J522101411210S
Q4406 963212500030S TR 2SA ISA1530AC1 J520015301210S
Q4407 943216500020S TR 2SC RT1N141C J522101411210S
Q4408 963212500030S TR 2SA ISA1530AC1 J520015301210S
D4401,4402 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4403-4410 963201500170D D,SWITCHING CHIP LBAS16HT1G K005041480230S
D4411,4412 963209003510S D,ESD CDS3C05HDMI1 K067030500010S
D4413 963209500020S D,ESD CDS3C15GTA K067031500010S
ZD4400 963202500330D D,ZENER ZJ6.8B-0.5W K06006R844522S
ZD4401 963202500350D D,ZENER ZJ22B-0.5W K06022R044522S
ZD4402 963202500340D D,ZENER ZJ15B-0.5W K06015R044522S
ZD4403-4405 963202500310D D,ZENER ZJ5.1B-0.5W K06005R144522S
LED4402 963263100620D LED,ROUND BL-BUBGJ201G-L K500032501150S
FL4400 943172100150S DISPLAY,FLT 018BT021GINK K530180210010S
LED4400 963262010460S LED SIR-341ST3F 3PI 2113CIE3 K505341300010S
RESISTORS
GROUP
R4418,4419 nsp 390-J,1/16W-1608 2113CIE3 C20003916M160S
R4421 nsp 47K-J,1/16W-1608 2113CIE3 C20004736M160S
R4426 00D9639006272 R,FIXED RSD-R1-1WJ-4.7 N113135647920S
R4464,R4479 nsp 4.7K-J,1/5W-52RE-AX
2113CIE3, 2113E2,
2113E1C
C00004726P520S
R4489,R4490 nsp 100-J,1/5W-52RE-AX
2113CIE3, 2113E2,
2113E1C
C00001016P520S
CAPACITORS GROUP
C4408 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4409 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4411 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4412 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4413 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4414 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C4415,4416 nsp C,FILM 0.1UF-J/100V D02010406C060S
C4417 nsp C,ELECT 47UF-M/16V D040470083080S
C4418 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4419,4420 nsp C,FILM 0.1UF-K/250V D02010407H080S
C4421 00D9630157900 C,ELECT 470UF-M/63V D040471088010S
C4422 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
