AVR-3805 / AVC-3890
PARTS LIST OF PACKING & ACCESSORIES
Ref. No. Part No. Part Name Remarks Q'ty New
201 504 0192 106 CABINET SHEET 1
202 503 1330 207 CUSHION ASS'Y 1
203 505 8006 019 ENVELOPE 1
204 511 4150 003 INST. MANUAL (EU) for EU,EC 1 *
204 511 4158 005 INST. MANUAL (E2) for E2 1 *
204 511 4167 009 INST. MANUAL (E1) for E2A,E1C,EUT 1 *
204 511 4168 008 INST. MANUAL (E1K) for E1K 1 *
204 511 4169 007 INST. MANUAL (N) for JP 1 *
204A 511 4157 006 INST. MANUAL (EC) for EC 1 *
205 511 4151 002 INST. SHEET (PRESET) 1 *
206 515 0921 209 S.S.LIST(EX) for EU,EC,E2,E2A,E1C,EUT,E1K 1
206 515 0918 209 SERVICE STATION LIST for JP 1
207 515 0944 008 WARRANTY (HOME) for EU,EC 1
208 231 0922 009 LOOP ANTENNA for EU,EC,E2,E2A,E1C,EUT,E1K 1
209 395 0029 002 FM ANT ASS'Y for EU,EC,E2,E2A,E1C,EUT,E1K 1
210 321 0037 006 OMNIDIRECTIONAL MICROPHONE for E2,E2A,E1C,EUT,E1K,JP 1 *
211 399 0944 008 REMOTE CONTROLLER RC-969 for EU,EC,E1C,EUT,E1K 1 *
211 399 0944 011 REMOTE CONTROLLER RC-970 for E2,E2A 1 *
211 399 0944 024 REMOTE CONTROLLER RC-971 for JP 1 *
212 206 2220 004 AC CORD SET (E3) for EU,EC 1
212 206 2215 006 AC CORD-E1/10A/INLET for E2,E2A,E1K 1
212 206 2189 006 AC CORD (E1C) for E1C 1
212 206 2150 103 AC CORD WITH CONN. for EUT 1
212 206 2141 002 AC CORD W/CON&PLUG for JP 1
213 - CONT.CARD(L) for EU,EC,E2,E2A,E1C,EUT,E1K 1
214 501 1950 199 SPACER 2
215 501 2255 042 CARTON CASE for EU,EC, 1 *
215 501 2255 055 CARTON CASE for E2,E2A,E1C,EUT,E1K 1 *
215 501 2255 013 CARTON CASE for JP 1 *
216 - UPC/POS LABEL for EU,EC,E2 1
216 998 0005 809 POS LABEL for JP 1
★
217
501 2262 006
PAD for E2,E2A,E1C,EUT,E1K,JP 1 *
★
218 GEN 6211-2 CARTON LABEL (C) for E1C 1 *
★
218 GEN 6072 H6 CARTON LABEL (T) for EUT 1 *
★
219 513 9111 001 COLOR LABEL (GOLD) for E2A,E1C,EUT,E1K 2
★
219 513 9111 056 COLOR LABEL (SILVER) for EU & E2 silver model 2
★
221 515 0919 004 GUARANTEE CARD(S) for JP 1
222 505 0038 072 POLY COVER (AC CORD) for E2,E2A,E1C,EUT,E1K 1
223 511 4205 000 ADDITIONAL SHEET for EU,EC, 1 *
223 511 4206 009 ADDITIONAL SHEET for E2 1 *
223 511 4207 008 ADDITIONAL SHEET for E2A,E1C,EUT 1 *
223 511 4208 007 ADDITIONAL SHEET for JP 1 *
Note : The symbols in the column “Remarks” indicate the following destinations.
EU : U.S.A. model E1C : China model
EC : Canada model EUT : Taiwan R.O.C. model
E2 : Europe model E1K : Korea model
E2A : Asia model JP : Japan model

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
