Denon AVR-3805 Service Manual

86
86
AVR-3805 / AVC-3890
CONNECT/VIDEO UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC251,252 262 2826 903 BU4051BCF
IC253,254 263 1082 903 TK15420MTL
IC255 262 2012 908 BU4052BCF-E2
IC256 262 2013 907 BU4053BCF-E2
IC257,258 263 1082 903 TK15420MTL
IC451 262 2827 902 MM74HC4053SJ
IC452 263 0682 003 NJM2229S
IC453 262 2808 002 M35015-210SP
IC501-503 263 1082 903 TK15420MTL
IC504-507 262 2826 903 BU4051BCF
IC508 263 1082 903 TK15420MTL
IC509,510 262 2012 908 BU4052BCF-E2
IC511,512 263 1082 903 TK15420MTL
IC703 262 3174 900 SN74AHCT08NS
IC705 262 3351 901 LMS202IMX *
TR201 271 0312 905 2SA/KTA1504SGR-RTK
TR202,203 269 0192 902 KRC102S-RTK(10K-10K)
TR455,456 273 0464 901 KTC3875SGR-RTK
TR501 271 0312 905 2SA/KTA1504SGR-RTK
TR502,503 269 0192 902 KRC102S-RTK(10K-10K)
TR601 271 0301 903 2SA/KTA1268BL-AT
TR603 273 0464 901 KTC3875SGR-RTK
TR604 271 0312 905 2SA/KTA1504SGR-RTK
TR605,606 273 0464 901 KTC3875SGR-RTK
TR607 271 0312 905 2SA/KTA1504SGR-RTK
TR608,609 273 0464 901 KTC3875SGR-RTK
TR610 271 0312 905 2SA/KTA1504SGR-RTK
TR611 273 0464 901 KTC3875SGR-RTK
TR701 269 0192 902 KRC102S-RTK(10K-10K)
TR702,703 271 0312 905 2SA/KTA1504SGR-RTK
TR704 269 0192 902 KRC102S-RTK(10K-10K)
TR901 271 0301 903 2SA/KTA1268BL-AT
TR902 274 0160 907 2SD2144STPU
TR903 273 0458 904 2SC/KTC3200BL-AT
TR904,905 271 0301 903 2SA/KTA1268BL-AT
TR906-909 269 0184 907 KRA102S-RTK
TR912 269 0184 907 KRA102S-RTK
TR913 271 0301 903 2SA/KTA1268BL-AT
TR956 269 0184 907 KRA102S-RTK
TR960,961 269 0191 903 KRA104S-RTK(47K-47K)
TR962,963 269 0193 901 KRC104S-RTK(47K-47K)
D201,202 276 0432 903 1SS270A TE (TAPE)
D453 276 0740 909 KDS184-RTK(K-COM)
D459 276 0432 903 1SS270A TE (TAPE)
D501,502 276 0432 903 1SS270A TE (TAPE)
D901-910 276 0723 900 RB721Q-40
D911 276 0432 903 1SS270A TE (TAPE)
D913 276 0704 903 1SR35-400A(T93X)
D915 276 0704 903 1SR35-400A(T93X)
D916 276 0461 916 HZS6A-2TD
D917 276 0704 903 1SR35-400A(T93X)
D918-921 276 0723 900 RB721Q-40
ZD701 276 0461 903 HZS6A-1TD
