AVR-3805 / AVC-3890
PARTS LIST OF P.W.B. UNIT ASS’Y (FOR EUROPE & ASIA)
POWER UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC201 263 1035 002 PQ30RV11
! IC502 268 0073 905 ICP-N15T
TR105,106 273 0458 904 2SC/KTC3200BL-AT
TR107 273 0464 901 KTC3875SGR-RTK
TR205 273 0458 904 2SC/KTC3200BL-AT
TR207 273 0464 901 KTC3875SGR-RTK
TR305,306 273 0458 904 2SC/KTC3200BL-AT
TR307,308 273 0464 901 KTC3875SGR-RTK
TR405,406 273 0458 904 2SC/KTC3200BL-AT
TR407 273 0464 901 KTC3875SGR-RTK
TR501 271 0094 919 2SA970(BL)TPE2
TR507 273 0464 901 KTC3875SGR-RTK
TR509,510 273 0464 901 KTC3875SGR-RTK
TR511 269 0192 902 KRC102S-RTK(10K-10K)
TR601-620 273 0460 905 KTC2875B-RTK
D101-107 276 0432 903 1SS270A TE (TAPE)
D201 276 0432 903 1SS270A TE (TAPE)
D203 276 0432 903 1SS270A TE (TAPE)
D205 276 0432 903 1SS270A TE (TAPE)
D207 276 0432 903 1SS270A TE (TAPE)
D301-308 276 0432 903 1SS270A TE (TAPE)
D401-407 276 0432 903 1SS270A TE (TAPE)
D501,502 276 0338 007 S4VB20F
D503-506 276 0704 903 1SR35-400A(T93X)
D507 276 0432 903 1SS270A TE (TAPE)
D508,509 276 0704 903 1SR35-400A(T93X)
ZD101-104 276 0461 903 HZS6A-1TD
ZD201 276 0461 903 HZS6A-1TD
ZD203 276 0461 903 HZS6A-1TD
ZD301-304 276 0461 903 HZS6A-1TD
ZD401-404 276 0461 903 HZS6A-1TD
ZD503 276 0463 914 HZS6C-2TD
ZD504 276 0645 907 MTZJ18A T77
RESISTORS GROUP
R103-106 241 2376 964 RD14B2E470JNBST
R107-114 244 2671 956 RS14B3DR47JNBST(S)
R125,126 244 2682 903 RS14B3D010JNBST(S)
R127,128 244 2671 901 RS14B3D100JNBST(S)
R129 247 2009 983 RM73B--103JT
R130 247 2009 909 RM73B--472JT (1608)
R203 241 2376 964 RD14B2E470JNBST
R205 241 2376 964 RD14B2E470JNBST
R207 244 2671 956 RS14B3DR47JNBST(S)
R209 244 2671 956 RS14B3DR47JNBST(S)
R211 244 2671 956 RS14B3DR47JNBST(S)
R213 244 2671 956 RS14B3DR47JNBST(S)
R214 245 2365 980 RN14K2E391FT(5)
R225 244 2682 903 RS14B3D010JNBST(S)

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
