Denon AVR-3805 Service Manual

93
93
AVR-3805 / AVC-3890
VIDEO CONV. UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC101 262 2013 907 BU4053BCF-E2
IC102-104 263 1082 903 TK15420MTL
IC105 262 2012 908 BU4052BCF-E2
IC108 262 2012 908 BU4052BCF-E2
IC109 262 3110 906 TC90A69F
IC110 263 1165 901 NJM2274R
IC111 262 3108 002 TA1270BF
IC112,113 263 1082 903 TK15420MTL
IC115 263 1082 903 TK15420MTL
IC117 263 1082 903 TK15420MTL
IC120 263 1040 903 BU4094BCF-E2
IC501 263 1167 006 TA8772AN
IC701,702 262 2549 002 LC75721E
IC703 268 0073 905 ICP-N15T
IC704 499 0303 004 GP1UM271XK
TR101,102 271 0312 905 2SA/KTA1504SGR-RTK
TR501,502 273 0464 901 KTC3875SGR-RTK
TR503 271 0312 905 2SA/KTA1504SGR-RTK
TR701 271 0312 905 2SA/KTA1504SGR-RTK
TR702 269 0193 901 KRC104S-RTK(47K-47K)
TR703 271 0312 905 2SA/KTA1504SGR-RTK
TR704,705 269 0193 901 KRC104S-RTK(47K-47K)
TR706 269 0191 903 KRA104S-RTK(47K-47K)
TR707 269 0193 901 KRC104S-RTK(47K-47K)
TR708 269 0191 903 KRA104S-RTK(47K-47K)
TR709 269 0193 901 KRC104S-RTK(47K-47K)
TR710 269 0191 903 KRA104S-RTK(47K-47K)
TR711 269 0193 901 KRC104S-RTK(47K-47K)
TR712 269 0191 903 KRA104S-RTK(47K-47K)
TR713 269 0193 901 KRC104S-RTK(47K-47K)
TR714 269 0191 903 KRA104S-RTK(47K-47K)
TR715 269 0193 901 KRC104S-RTK(47K-47K)
TR716 269 0191 903 KRA104S-RTK(47K-47K)
TR717 269 0193 901 KRC104S-RTK(47K-47K)
TR718 269 0191 903 KRA104S-RTK(47K-47K)
TR719 269 0193 901 KRC104S-RTK(47K-47K)
TR720 269 0191 903 KRA104S-RTK(47K-47K)
TR721 269 0193 901 KRC104S-RTK(47K-47K)
TR722 269 0191 903 KRA104S-RTK(47K-47K)
TR723 269 0193 901 KRC104S-RTK(47K-47K)
TR724 269 0191 903 KRA104S-RTK(47K-47K)
TR725 269 0193 901 KRC104S-RTK(47K-47K)
TR726 269 0191 903 KRA104S-RTK(47K-47K)
TR727 269 0193 901 KRC104S-RTK(47K-47K)
TR728 269 0191 903 KRA104S-RTK(47K-47K)
TR729 269 0193 901 KRC104S-RTK(47K-47K)
TR730 269 0191 903 KRA104S-RTK(47K-47K)
TR731 269 0193 901 KRC104S-RTK(47K-47K)
TR732 269 0191 903 KRA104S-RTK(47K-47K)
TR733 269 0193 901 KRC104S-RTK(47K-47K)
TR734 269 0191 903 KRA104S-RTK(47K-47K)
TR735 269 0193 901 KRC104S-RTK(47K-47K)
TR736 269 0191 903 KRA104S-RTK(47K-47K)
TR737 269 0193 901 KRC104S-RTK(47K-47K)
TR738 269 0191 903 KRA104S-RTK(47K-47K)

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
