Denon AVR-3805 Service Manual

64
64
AVR-3805 / AVC-3890
AMP CONNECT UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC601 263 1048 002 BA033T
IC602 263 1179 007 NJM7805FA(SS)-#4MS
IC603 263 0554 005 NJM7905FA
IC604 263 1100 047 KIA7820API
IC605 263 1100 005 KIA7805API
IC606 263 1163 000 KIA78R09PI
TR107-110 271 0094 919 2SA970(BL)TPE2
TR111,112 273 0471 907 KTC3206Y-AT
TR113,114 271 0314 903 KTA1024Y-AT
TR115,116 273 0471 907 KTC3206Y-AT
TR207 271 0094 919 2SA970(BL)TPE2
TR209 271 0094 919 2SA970(BL)TPE2
TR211 273 0471 907 KTC3206Y-AT
TR213 271 0314 903 KTA1024Y-AT
TR215 273 0471 907 KTC3206Y-AT
TR307-310 271 0094 919 2SA970(BL)TPE2
TR311,312 273 0471 907 KTC3206Y-AT
TR313,314 271 0314 903 KTA1024Y-AT
TR315,316 273 0471 907 KTC3206Y-AT
TR407-410 271 0094 919 2SA970(BL)TPE2
TR411,412 273 0471 907 KTC3206Y-AT
TR413,414 271 0314 903 KTA1024Y-AT
TR415,416 273 0471 907 KTC3206Y-AT
TR601 272 0158 007 2SB/KTB778(R/O)
TR602 271 0313 904 KTA1281Y-AT
TR603 273 0468 907 2SC/KTC3199GR-AT
TR604 269 0206 908 KRC102M-AT(10K-10K)
TR605 271 0313 904 KTA1281Y-AT
TR606 273 0469 906 2SC/KTC3209Y-AT
TR607 273 0468 907 2SC/KTC3199GR-AT
TR608 271 0311 906 2SA/KTA1267GR-AT
TR609 269 0206 908 KRC102M-AT(10K-10K)
TR610 271 0313 904 KTA1281Y-AT
TR611 273 0468 907 2SC/KTC3199GR-AT
TR612 269 0206 908 KRC102M-AT(10K-10K)
TR613 274 0198 005 2SD/KTD998(R/O)
TR614 272 0158 007 2SB/KTB778(R/O)
TR615 273 0468 907 2SC/KTC3199GR-AT
TR616 271 0311 906 2SA/KTA1267GR-AT
TR617,618 275 0042 905 2SK373(Y)TPE2
TR619 273 0468 907 2SC/KTC3199GR-AT
TR620 269 0206 908 KRC102M-AT(10K-10K)
TR621 273 0468 907 2SC/KTC3199GR-AT
TR622 272 0158 007 2SB/KTB778(R/O)
TR623 274 0198 005 2SD/KTD998(R/O)
TR624 269 0206 908 KRC102M-AT(10K-10K)
TR625 269 0204 900 KRA102M-AT(10K-10K)
D101-106 276 0432 903 1SS270A TE (TAPE)
D201 276 0432 903 1SS270A TE (TAPE)
D203 276 0432 903 1SS270A TE (TAPE)
D205 276 0432 903 1SS270A TE (TAPE)
D301-306 276 0432 903 1SS270A TE (TAPE)
D401-406 276 0432 903 1SS270A TE (TAPE)
D510 276 0432 903 1SS270A TE (TAPE)
