Denon AVR-3805 Service Manual

81
81
AVR-3805 / AVC-3890
CONTROL UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC501 262 2580 906 CXA1511M
IC503 263 1040 903 BU4094BCF-E2
IC505 263 1048 002 BA033T
IC506 GEN6626 MAIN CPU SUB ASS’Y M30624FGAFP(3805-M) *
IC507 262 2813 903 SN74AHCT08PW-EL2
IC701 263 1100 021 KIA7812API
IC702 263 0432 907 NJM78L05AT
IC801 262 3360 905 LC72722PM-TML
TR201 273 0464 901 KTC3875SGR-RTK
TR202 271 0310 907 2SA1163(BL)
TR203 273 0464 901 KTC3875SGR-RTK
TR204 269 0144 905 DTC114YK-T146
TR205 273 0464 901 KTC3875SGR-RTK
TR206 269 0192 902 KRC102S-RTK(10K-10K)
TR207 273 0464 901 KTC3875SGR-RTK
TR501 269 0184 907 KRA102S-RTK
TR505 269 0191 903 KRA104S-RTK(47K-47K)
TR509 272 0161 900 2SB1412TL(PQR)
TR510 269 0192 902 KRC102S-RTK(10K-10K)
TR513 272 0161 900 2SB1412TL(PQR)
TR514-516 269 0192 902 KRC102S-RTK(10K-10K)
TR517 272 0161 900 2SB1412TL(PQR)
TR518 269 0192 902 KRC102S-RTK(10K-10K)
TR519 269 0193 901 KRC104S-RTK(47K-47K)
TR520 269 0191 903 KRA104S-RTK(47K-47K)
TR521-523 269 0193 901 KRC104S-RTK(47K-47K)
TR524 273 0464 901 KTC3875SGR-RTK
TR701,702 269 0066 902 DTC323TKT96
TR703 269 0086 908 DTA114TKT96
TR704,705 269 0192 902 KRC102S-RTK(10K-10K)
TR706,707 272 0161 900 2SB1412TL(PQR)
TR708,709 269 0192 902 KRC102S-RTK(10K-10K)
TR801 273 0464 901 KTC3875SGR-RTK
D201-204 276 0740 909 KDS184-RTK(K-COM)
D501,502 276 0704 903 1SR35-400A(T93X)
D503 276 0432 903 1SS270A TE (TAPE)
D504 276 0454 910 HZS3C-2TD
D505 276 0432 903 1SS270A TE (TAPE)
RESISTORS GROUP
R101-103 247 2007 943 RM73B--102JT
R104-106 247 2005 916 RM73B--111JT
R107-109 247 2005 932 RM73B--131JT
R110-112 247 2005 961 RM73B--181JT
R113,114 247 2005 990 RM73B--241JT
R115,116 247 2006 902 RM73B--331JT (1608)
R117,118 247 2006 973 RM73B--511JT
R119,120 247 2007 927 RM73B--821JT
R121 247 2007 998 RM73B--162JT
R201-209 247 2012 925 RM73B--104JT
R214 247 2008 926 RM73B--222JT

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
