Denon AVR-3805 Service Manual

68
68
AVR-3805 / AVC-3890
DSP ADI EX UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC301 262 3339 907 SN74LVC139APWR *
IC302,303 262 2642 909 SN74LV573APW-EL2
IC304 263 1205 900 PQ012FZ01ZP *
IC311 262 3292 905 FCX0-03(25.000M/L) *
IC312 GEN6628 DSP SUB ASS’Y ADSP-21266SKBCZ-2B *
IC313 262 3353 006 LH28F160BJE(3805) *
IC314,315 262 3341 005 CY7C1049CV33-10ZC *
TR301 269 0184 907 KRA102S-RTK
D301 276 0750 902 RB521S-30TE61
RESISTORS GROUP
R303 247 2018 903 RM73B--0R0KT
R307 247 2018 903 RM73B--0R0KT
R309 247 2018 903 RM73B--0R0KT
R311 247 2018 903 RM73B--0R0KT
R312,313 247 2009 983 RM73B--103JT
R314-316 247 2008 955 RM73B--302JT
R317-334 247 2005 903 RM73B--101JT
R335 247 2009 983 RM73B--103JT
R336 247 2004 920 RM73B--470JT
R337,338 247 2009 983 RM73B--103JT
R340 247 2009 983 RM73B--103JT
R347 247 2009 983 RM73B--103JT
R351 247 2018 903 RM73B--0R0KT
R352 247 2011 942 RM73B--473JT
R353,354 247 2009 983 RM73B--103JT
R356 247 2009 983 RM73B--103JT
R357-359 247 2018 903 RM73B--0R0KT
R360-362 247 2003 989 RM73B--330JT
R363,364 247 2009 983 RM73B--103JT
R365 247 2005 903 RM73B--101JT
R366,367 247 2009 983 RM73B--103JT
R369 247 2004 962 RM73B--680JT
R370,371 247 2018 903 RM73B--0R0KT
R372-378 247 2003 989 RM73B--330JT
R378,379 247 2018 903 RM73B--0R0KT
R380 247 2003 989 RM73B--330JT
R381,382 247 2004 920 RM73B--470JT
R383 247 2004 962 RM73B--680JT
R384,385 247 2003 989 RM73B--330JT
R386,387 247 2018 903 RM73B--0R0KT
R388,389 247 2004 920 RM73B--470JT
R390-396 247 2018 903 RM73B--0R0KT
R397 247 2005 990 RM73B--241JT
R398-401 247 2004 920 RM73B--470JT
R402-405 247 2018 903 RM73B--0R0KT
R406 247 2003 989 RM73B--330JT
R407 247 2018 903 RM73B--0R0KT
R408-410 247 2009 983 RM73B--103JT
R411 247 2018 903 RM73B--0R0KT

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
