Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting Specifications
a
i/p Scaler
Make settings for i/p scaler function.
[Selectable items] A to H
A to H & H to H
OFF
HDMI Setup
Make settings for HDMI video/audio output.
F Menu tree F
Manual Setup
HDMI Setup
a i/p Scaler
s Resolution
d Progressive Mode
f Aspect
g Color Space
h RGB Range
j Auto Lip Sync
k Audio
l Monitor Out
s
Resolution
Make settings for resolution of HDMI video output signal.
[Selectable items] Auto
480p/576p
1080i
720p
1080p
NOTE
• It is not possible to convert “1080i” signals into “720p” format.
• It is not possible to convert “720p” signals into “1080i” format.
This can be set when “i/p Scaler” is set to anything other than “OFF”.
d
Progressive Mode
Select optimum progressive mode for video material.
[Selectable items]
Auto
Video1
Video2
This can be set when “i/p Scaler” is set to anything other than “OFF”.
f
Aspect
This sets the aspect ratio when outputting 480i/576i or
480p/576p input signals from the HDMI output connector.
[Selectable items] Full
Normal
This can be set when “i/p Scaler” is set to anything other than “OFF”.
g
Color Space
Make settings for output color space.
[Selectable items]
YCbCr
RGB
When connected to a monitor with a DVI-D connector (HDCP
compatible) using an HDMI/DVI converter cable, the signals are output
in RGB format, regardless of this setting.
h
RGB Range
Make settings for RGB output range.
[Selectable items] Normal
Enhanced
A to H & H to H setting
• Deep color (10 bit/12 bit) signals are converted into 8-bit signals.
• The i/p scaler function does not work if xvYCC or computer’s
resolution signals are input.
j
Auto Lip Sync
Automatic compensation for timing shift in audio and video
output.
[Selectable items] ON
OFF
k
Audio
Select HDMI audio output device.
[Selectable items] Amp
TV
l
Monitor Out
Make settings for HDMI monitor output.
[Selectable items] Auto (Dual)
Monitor 1
Monitor 2
Operating from the main remote control unit
Press the M.SEL button.
Auto (Dual) Monitor 1
Monitor 2
Setup
• When “Monitor Out” is set to “Auto (Dual)”, connections with
the MONITOR 1 or MONITOR 2 connectors are recognized
automatically.
• If both the MONITOR 1 and 2 connectors are connected and
“Resolution” is set to “Auto”, the signals are output with a resolution
compatible with both monitors.
• If “Resolution” is set to something other than “Auto”, check the
resolutions with which your monitor is compatible at GUI menu
“Information” – “HDMI Information” – “Monitor 1” and “Monitor 2”
and set accordingly (vpage 48).
When “YCbCr” is selected under “Color Space”, “RGB Range” will
have no effect.
NOTE
Depending on the monitor you have connected, the display may not
be correct when you set to "Auto (Dual)". In such a case, set to either
“Monitor 1” or “Monitor 2”.
To Next Page
