106
AVR-1707/1507/687/587/487
PACKING VIEW
PARTS LIST OF PACKING & ACCESSORIES (for AVR-1707/687 model)
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
1707E3 : U.S.A. & Canada model (AVR-1707) E2 : Europe model (AVR-1707) EUT : Taiwan R.O.C. model (AVR-1707)
687E3 : U.S.A. & Canada model (AVR-687)
Ref. No. nsp Part No. Part Name Remarks ETRO Q'ty New
1 00D 513 4107 007 XM SHEET E3,687E3 1
2 00D 963 0285 306 INSTRUCTION MANUAL E3 5707210130050S 1 *
2 00D 963 0285 306 INSTRUCTION MANUAL 687E3 5707210130050S 1 *
2 00D 963 0285 403 INSTRUCTION MANUAL E2 5707210130060S 1 *
2 00D 963 0285 500 INSTRUCTION MANUAL EUT 5707210130070S 1 *
3 00D 231 0089 007 AM LOOP ANTENNA 1
4 00D 963 0158 006 FM ANTENNA WIRE E605010070001S 1
5 00D 963 0286 208 REMOTE CONTROL RC-1048 E3,687E3 8300010480010S 1 *
5 00D 963 0286 305 REMOTE CONTROL RC-1049 E2,EUT 8300010490010S 1 *
6 nsp 00D 963 0045 106 POLY BAG 6330000240000S 1
7 00D 963 0193 101 CUSHION,SNOW 6230210154001S 1
8 00D 963 0285 908 BOX GIFT E3 6007210310620S 1 *
8 00D 963 0301 701 BOX,GIFT E2 6007210310700S 1 *
8 00D 963 0286 004 BOX,GIFT 687E3 6007210310630S 1 *
8 00D 963 0286 101 BOX,GIFT EUT 6007210310640S 1 *
9 - WARRANTY CARD E3,687E3 5777001610035S 1
AVR-1707/1507/687/587/487 E3 model
AVR-1707/1507 E2 model
AVR-1707 EUT model
To Next Page
