Denon AVR-487 Service Manual

50
AVR-1707/1507/687/587/487
CPU P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D 262 3651 009 M3062LFGPFP
IC202 00D 963 0057 602 IC TDA7330BD 1707E2 J080733000010F
IC272 00D 963 0219 301 IC CJ7806 J126780600190S
IC273 00D 963 0235 107 IC CJ7906F J126790600040S
IC301 00D 262 2549 002 LC75721E +C
IC302 00D 963 0074 504 IC BU2090F J044209000010P
Q202 00D 963 0121 509 TR KTC3875S J522038750210S
Q203,204 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q205 00D 963 0120 704 TR KRA102S J520010200210S
Q206,207 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q251 00D 963 0120 704 TR KRA102S J520010200210S
Q261 00D 963 0148 508 TR KTA1504S 1707E2 J520015040150S
Q262 00D 960 0111 808 TR KRC107S 1707E2 J5020107S0050S
Q263 00D 960 0285 006 TR KRC104S J522104S00210S
Q301 00D 963 0120 704 TR KRA102S J520010200210S
Q310 00D 963 0120 704 TR KRA102S J520010200210S
Q311 00D 963 0120 801 TR KRC102S J522010200210S
Q312 00D 963 0120 704 TR KRA102S J520010200210S
Q313 00D 963 0120 801 TR KRC102S J522010200210S
Q314 00D 963 0120 704 TR KRA102S J520010200210S
Q315 00D 963 0120 801 TR KRC102S J522010200210S
Q321 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q322 00D 960 0111 808 TR KRC107S J5020107S0050S
Q901,902 00D 963 0120 704 TR KRA102S J520010200210S
D201 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D202 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D203-205 00D 963 0219 709 D,SWITCHING 1N4148W 1707E3,687E3,1707EUT K005041480020S
D203-206 00D 963 0219 709 D,SWITCHING 1N4148W 1707E2 K005041480020S
D209,210 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D302-304 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D305 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D307 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D308,309 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
ZD201 00D 963 0047 502 D,ZENER MTZJ3.3B K06003R344520S
ZD301 00D 960 0095 801 D,ZENER MTZJ6.8B K06006R844520S
ZD331,332 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
ZD335,336 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
LED301-304 00D 960 0197 204 LED PI5-RD/HL50RDRF4T K500052015010S
LED306 00D 960 0197 204 LED PI5-RD/HL50RDRF4T K500052015010S
LED308-311 00D 960 0197 204 LED PI5-RD/HL50RDRF4T K500052015010S
FL301 00D 963 0257 305 DISPLAY,FLT HNA-16SM13T K530161300020S
RESISTORS GROUP
R211 00D 960 9003 807 R,METAL FILM 100-J,1/4W C060010163050S
CAPACITORS GROUP
C201 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C202 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160S
C203 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C204 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C205 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C206 00D 963 9005 862 C,ELECT 47UF-M/16V 1707E2 D040470083080F
C207 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V 1707E2 D011103777160S
