Denon AVR-487 Service Manual

48
AVR-1707/1507/687/587/487
C155 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C157 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C158 00D 963 0217 002 C,ELECT 3300UF-M/16V D040332083010F
C159 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C161 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C171 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C171A 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C171B 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C171C 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C171D 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C172,173 00D 963 9005 833 C,ELECT 220UF-M/6.3V D040221081230F
C174 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C175 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050F
C176,177 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C178 00D 963 9003 149 C,ELECT 330UF-M/63V D040331088230F
C179 00D 963 9005 833 C,ELECT 220UF-M/6.3V D040221081230F
! C181 00D 963 9006 191 C,CERAMIC AC(SAFETY)
AC13F472MDOA
D00847208K070S
C182 00D 963 0234 302 C,ELECT 10UF-M/100V D04010008C050F
C191-198 00D 963 0233 400 C,CERAMIC 2200PF-K/16V 1707E2 D005222773530S
C198C 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C198FL 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C198FR 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C198SBL 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C198SBR 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C198SL 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C198SR 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C199 00D 963 0233 400 C,CERAMIC 2200PF-K/16V 1707E2 D005222773530S
C199FL 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C199FR 00D 963 0024 703 C,FILM 0.01UF-J/100V 1707E2 D02010306C060P
C341,342 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C901,902 00D 963 0233 206 C,CERAMIC 0.001UF-K/50V D005102177530S
C903 00D 963 0233 109 C,CERAMIC 0.01UF-Z/50V D004103097060S
C904 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C905 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
OTHERS PARTS GROUP
CLAMP101 nsp 00D 960 0260 005 CLAMP WIRE 4330000120000S
CN201 nsp 00D 963 0148 702 CN,WIRE 120MM/2P L000121020120P
CN901 00D 963 0184 601 CN,WIRE 260MM/3P L000261030070P
CN992 nsp 00D 963 0235 602 CN,WIRE 270MM/4P L000271040030P
CP101 00D 963 0267 803 CN.WAFER 2P L108202000220F
CP102 nsp 00D 960 0123 304 CN.WAFER 2P L104353280200S
CP103 nsp 00D 963 0066 208 CN.WAFER 3P L104353280300S
CP104 nsp 00D 960 0128 804 CN.WAFER 6P L102526700600S
CP105 nsp 00D 963 0149 109 CN.WAFER (BLACK) 2P L104353280201S
CP106 nsp 00D 960 0123 207 CN.WAFER 3P L102526700300S
CP138A nsp 00D 960 0123 207 CN.WAFER 3P L102526700300S
CP302 00D 963 0257 800 CN.WAFER 07P L101220070010S
CP501 nsp 00D 963 0206 301 CN.WAFER 5P L101100040510S
CP502 nsp 00D 963 0206 408 CN.WAFER 7P L101100040710S
CP503 nsp 00D 963 0206 301 CN.WAFER 5P L101100040510S
CP504 nsp 00D 963 0206 505 CN.WAFER 9P L101100040910S
CP505 nsp 00D 963 0235 709 CN.WAFER 12P L101100041210S
CP555 nsp 00D 963 0111 108 CN.WAFER 14P L101100041410S
CP556 nsp 00D 963 0087 805 CN.WAFER 11P L101100041110S
CP901,902 nsp 00D 963 0235 806 CN.WAFER 3P L101220030000S
CP931 nsp 00D 963 0149 206 CN.WAFER 2P L104353280203S
! F101 00D 963 0236 106 FUSE T8A/250V 1707E3,687E3,1707EUT N751228001110S
! F101 00D 963 0104 704 FUSE T2.5A/250V 1707E2 N751222501110S
Ref. No. nsp Part No. Part Name Remarks Q'ty New
