Denon AVR-487 Service Manual

89
AVR-1707/1507/687/587/487
DSP1 P.W.B. UNIT ASSY (for AVR-1507E2 model)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC802,803 00D 963 0237 503 JSR1165-C /OPTICAL E100116500040S
IC804 00D 262 3662 001 ADSP21266SKSTZ-1B-AC
IC805 00D 262 3652 008 LH28F800BJE(1707)
IC806 00D 262 3536 001 AS7C34096A-10TCN
IC807 00D 262 3066 102 LC89057W-VF4-E(AC) +REF
IC808 00D 262 3645 002 IC ADAU1328BSTZ
IC809-811 00D 960 0266 805 IC MM74LCX244 J040742440180P
IC812 00D 960 0266 902 IC MM74HCT244 J040742440190P
IC814,815 00D 963 0218 904 IC MM74HCT00MTCX J040740000200P
IC815A 00D 963 0043 807 IC BA4510F J121451000010P
IC816 00D 262 2870 904 74LVX157MTC +C
IC816A 00D 963 0043 807 IC BA4510F J121451000010P
IC817 00D 262 3536 001 AS7C34096A-10TCN
IC817A 00D 963 0202 305 IC NJM2068M J121206800020S
IC818 00D 262 2642 909 SN74LV573APWR +REF
IC818A 00D 963 0202 305 IC NJM2068M J121206800020S
IC819 00D 262 2642 909 SN74LV573APWR +REF
IC819A 00D 963 0202 305 IC NJM2068M J121206800020S
IC820 00D 262 3339 907 SN74LVC139APWR +REF
IC820A 00D 963 0202 305 IC NJM2068M J121206800020S
IC821 00D 262 2870 904 IC 74LCX74MTC
IC822 00D 960 0296 008 IC CJ7805F J126780500400S
IC823 00D 963 0295 309 IC RC1117-33 J126111733020F
IC824 00D 963 0147 509 IC FAN1112-1.2 J126111712010F
IC825 00D 262 2870 904 IC 74LCX74MTC
IC827 00D 963 0219 107 IC MM74HC151MTCX J040741510050P
IC828 00D 963 0219 000 IC 74VHCU04 J040740400270P
IC829 00D 963 0244 907 IC SN74LV14APWR J040741400180P
IC830 00D 262 2813 903 IC SN74AHCTO8
Q804C 00D 960 0196 603 TR KTC2874B J502287400010S
Q804FL 00D 960 0196 603 TR KTC2874B J502287400010S
Q804FR 00D 960 0196 603 TR KTC2874B J502287400010S
Q804SBL 00D 960 0196 603 TR KTC2874B J502287400010S
Q804SBR 00D 960 0196 603 TR KTC2874B J502287400010S
Q804SL 00D 960 0196 603 TR KTC2874B J502287400010S
Q804SR 00D 960 0196 603 TR KTC2874B J502287400010S
Q804SW 00D 960 0196 603 TR KTC2874B J502287400010S
Q808 00D 963 0120 801 TR KRC102S J522010200210S
Q809 00D 963 0120 704 TR KRA102S J520010200210S
Q811,812 00D 963 0245 100 D,SWITCHING KDS226ST1 K005022600020S
D803 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
RESISTORS GROUP
R831-833 nsp 00D 963 0234 603 COIL,BEAD D340160800060S
CAPACITORS GROUP
C801 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C802,803 nsp 00D 963 9004 591 C,CERAMIC 22PF-J/50V D010220167160S
C807 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C808 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C812 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C813 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C814 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C815 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C816 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C817 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C818 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C819 00D 963 9005 901 C,ELECT 470UF-M/10V, D040471082060F
