Denon AVR-487 Service Manual

58
AVR-1707/1507/687/587/487
INPUT P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC701 00D 963 0295 202 IC NJW1197 J084119700010
IC701M 00D 963 0202 305 IC NJM2068M J121206800020S
IC705 00D 963 0202 305 IC NJM2068M 1707E3,687E3 J121206800020S
IC761-763 00D 963 0202 305 IC NJM2068M J121206800020S
Q755 00D 963 0121 004 TR KRC104M 1707E3,687E3 J502104000010S
Q760 00D 963 0121 004 TR KRC104M J502104000010S
Q771 00D 963 0121 004 TR KRC104M J502104000010S
Q772 00D 960 0097 207 TR KRA102M J6002202M0010S
Q773,774 00D 960 0196 807 TR 2SK117Y J5441170Y0050
D703-706 00D 963 0219 709 D,SWITCHING 1N4148W 1707E3,687E3 K005041480020S
D753 00D 963 0219 709 D,SWITCHING 1N4148W 1707E3,687E3 K005041480020S
D756 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D771,772 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
ZD701 00D 960 0222 603 D,ZENER MTZJ7.5A K06007R544530S
ZD701M 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
ZD702 00D 960 0222 603 D,ZENER MTZJ7.5A K06007R544530S
RESISTORS GROUP
R709M - R,CHIP 1.6K-J,1/10W C200016260200F
R731,732 00D 963 9005 668 R,METAL FILM 220-J,1W C060022165050S
R753 00D 960 9004 301 R,METAL FILM 47-J,1/4W 1707E3,687E3 C060047063050S
R756 00D 960 9004 301 R,METAL FILM 47-J,1/4W C060047063050S
R771,772 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R791,792 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
CAPACITORS GROUP
C481C nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C481FL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C481FR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C481SW nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C701L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C701M 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C701R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C702CH nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V 1707E3,687E3 D011103777160S
C702L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C702M 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C702R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C703CH nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V 1707E3,687E3 D011103777160S
C703L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C703M nsp 00D 963 0157 609 C,CERAMIC 150PF-J/50V D010151167160S
C703R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C704L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C704M nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C704R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C705L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C705M 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C705R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C706L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C706M nsp 00D 963 0157 609 C,CERAMIC 150PF-J/50V D010151167160S
C706R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C707 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C707M nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C708 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C708M 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C709 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C709M nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160S
C710M 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
