Denon AVR-487 Service Manual

53
AVR-1707/1507/687/587/487
PRE-AMP P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC102X 00D 263 1092 003 BA05T 1707E3,687E3
IC103X 00D 263 1223 005 PQ20RX11J00H 1707E3,687E3
Q101SBL 00D 963 0044 204 TR 2SD2390-Y J5032390Y0000P
Q101SBR 00D 963 0044 204 TR 2SD2390-Y J5032390Y0000P
Q101X 00D 960 0097 304 TR KRC102M 1707E3,687E3 J6020102M0010S
Q102SBL 00D 963 0044 107 TR2SB1560-Y J5011560Y0000P
Q102SBR 00D 963 0044 107 TR2SB1560-Y J5011560Y0000P
Q102X 00D 960 0097 304 TR KRC102M 1707E3,687E3 J6020102M0010S
Q103SBL 00D 963 0280 107 TR 2SC3964 J502396400000S
Q103SBR 00D 963 0280 107 TR 2SC3964 J502396400000S
Q104SBL 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q104SBR 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q501C 00D 960 0196 603 TR KTC2874B J502287400010S
Q501FL 00D 960 0196 603 TR KTC2874B J502287400010S
Q501FR 00D 960 0196 603 TR KTC2874B J502287400010S
Q501SL 00D 960 0196 603 TR KTC2874B J502287400010S
Q501SR 00D 960 0196 603 TR KTC2874B J502287400010S
Q502C 00D 960 0196 205 TR KSA992F J5000992F0050P
Q502FL 00D 960 0196 205 TR KSA992F J5000992F0050P
Q502FR 00D 960 0196 205 TR KSA992F J5000992F0050P
Q502SBL 00D 960 0196 205 TR KSA992F J5000992F0050P
Q502SBR 00D 960 0196 205 TR KSA992F J5000992F0050P
Q502SL 00D 960 0196 205 TR KSA992F J5000992F0050P
Q502SR 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503C 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503FL 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503FR 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503SBL 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503SBR 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503SL 00D 960 0196 205 TR KSA992F J5000992F0050P
Q503SR 00D 960 0196 205 TR KSA992F J5000992F0050P
Q504C 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q504FL 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q504FR 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q504SBL 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q504SBR 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q504SL 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q504SR 00D 960 0196 506 TR KSC1845F J5021845F0000P
Q506SBL 00D 960 0196 603 TR KTC2874B J502287400010S
Q506SBR 00D 960 0196 603 TR KTC2874B J502287400010S
D101SBL 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D101SBR 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102SBL 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102SBR 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D102X 00D 963 0058 407 D,SWITCHING IN4007 1707E3,687E3 K000400700520S
D102X1 00D 963 0058 407 D,SWITCHING IN4007 1707E3,687E3 K000400700520S
D106,107 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
ZD101SBL 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD101SBR 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD102SBL 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
ZD102SBR 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
RESISTORS GROUP
R104SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R104SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
