Denon AVR-5803 Service Manual

69
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks
C311,312 257 0511 917 Ceramic chip 0.022uF/50V CK73F1H223Z
for E2,E1,E1C,EUT
C401-404 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C406,407 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C408 254 4305 968 Electrolytic 1uF/50V CE04W1H010M (SRE)
C411 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
for EU,EC
C953 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
C957 256 1058 971 Metallized 0.1uF/50V CF93A1H104J (JL)
OTHER PARTS GROUP Q'ty
AC601 203 3946 003 AC outlet (POLARIZED) for EU,EC,EUT 1
CW074 204 2930 000 8P KR-DA connector cord 1
CW103 204 2845 001 10P KR-DA connector cord 1
CX033 205 0355 033 3P KR connector base (L) for EU,EC 1
CX074 205 0343 087 8P connector base (KR-PH) 1
CX103 205 0375 000 10P connector base (KR-PH) 1
CY021 205 1093 006 2P VH connector base
for E2,E1,E1C,EUT 1
CY025 205 0581 001 2P VH connector base for EU,EC,EUT 1
CY033 203 4834 088 3P KR-DA connector cord for EU,EC 1
CY041 205 0343 045 4P connector base (KR-PH) 1
CY127 205 0375 026 12P connector base (KR-PH) 1
CY291 205 1101 008 29P FFC connector base (L) 1
JK301,302 204 8514 006 4P pin jack (S-GND) 2
JK951 204 8217 031 Headphone jack (BK(AU)) 1
L101 235 0060 989 Inductor 120uH 1
S171 212 0415 007 Rotary encoder (EC16B36) 1
S401,402 212 0373 000 Rotary encoder (EC16B) 2
S403-420 212 5604 910 Tact switch 18
S421 212 0373 000 Rotary encoder (EC16B) 1
S422,423 212 5604 910 Tact switch 2
S424 212 1030 009 Power switch (TV-5) for E2,E1,E1C,EUT
S429 212 0420 005 1P push switch (NON LOCK) for EU,EC 1
W101 203 0605 004 1P SIN connector cord 1
W102 203 0605 059 1P SIN connector cord 1
W103 203 0605 046 1P SIN connector cord 1
W401 203 0605 033 1P SIN connector cord 1
W714 203 0440 065 1P contact Ass'y 1
W744 203 0526 073 1P contact Ass'y 1
Ref. No. Part No. Part Name Remarks
1U-3460(1U-3294G)/3460A
REG. & SP P.W.B. UNIT ASS'Y
SEMICONDUCTORS GROUP
IC302 263 0809 006 IC NJM7805FA (S)
IC304 263 1048 002 IC BA033T
IC306 263 0809 006 IC NJM7805FA (S)
IC307 263 0554 005 IC NJM7905FA
IC312 263 0812 006 IC NJM7815FA (S)
IC313 263 0561 001 IC NJM7915FA
TR313 273 0303 910 Transistor 2SC1740S (S)
TR315 273 0303 910 Transistor 2SC1740S (S)
TR317 273 0303 910 Transistor 2SC1740S (S)
TR318 271 0192 905 Transistor 2SA933S (S)
TR319 271 0117 906 Transistor 2SA1020 (Y)
TR322 271 0117 906 Transistor 2SA1020 (Y)
TR324 271 0117 906 Transistor 2SA1020 (Y)
TR325 273 0212 904 Transistor 2SC2655 (Y)
TR326-328 269 0020 906
Transistor DTC114ES (10K-10K)
TR501 273 0303 910 Transistor 2SC1740S (S)
D305 276 0432 903 Diode 1SS270A
D307 276 0432 903 Diode 1SS270A
D313-316 276 0432 903 Diode 1SS270A
D501-504 276 0706 008 Diode FCH20A15
PT510 279 0034 012 Posistor PTH9M04BG222TS2F333
RESISTORS GROUP
R316 241 2376 919 Carbon film 30ohm 1/4W (NB) RD14B2E300JNBS
R318 241 2376 919 Carbon film 30ohm 1/4W (NB) RD14B2E300JNBS
R320,321 241 2376 919 Carbon film 30ohm 1/4W (NB) RD14B2E300JNBS
R328,329 241 2376 919 Carbon film 30ohm 1/4W (NB) RD14B2E300JNBS
R506-511 243 2039 032 Winding 0.1ohm 5W RW99=3H0R1K
CAPACITORS GROUP
C310 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C316 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C318,319 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C320,321 254 4557 936 Electrolytic 10uF/50V CE04W1H100M (RFS)
C323 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C327 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C331 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C334 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C336,337 254 4313 963 Electrolytic 1uF/50V CE04W1H010M (ASF)
C340-343 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C359,360 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C401-403 255 4232 937 Polypropylene film 1000pF/100V CQ93P2A102J (NH)
for E2,E1,E1C,EUT
