Denon AVR-5803 Service Manual

85
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R307 247 2008 926 Carbon chip 2.2kohm 1/16W RM73B--222J
R308 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R309 247 2003 934 Carbon chip 20ohm 1/16W RM73B--200J
R310 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R311 247 2008 900 Carbon chip 1.8kohm 1/16W RM73B--182J
R312 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R313 247 2013 982 Carbon chip 470kohm 1/16W RM73B--474J
R314,315 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R316 247 2006 944 Carbon chip 390ohm 1/16W RM73B--391J
R317 247 2007 985 Carbon chip 1.5kohm 1/16W RM73B--152J
R318 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R319 247 2011 955 Carbon chip 51kohm 1/16W RM73B--513J
R320 247 2009 954 Carbon chip 7.5kohm 1/16W RM73B--752J
R321 247 2011 900 Carbon chip 33kohm 1/16W RM73B--333J
R322,323 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R324 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R325 247 2004 920 Carbon chip 47ohm 1/16W RM73B--470J
R326-329 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R331 247 2007 956 Carbon chip 1.1kohm 1/16W RM73B--112J
R332 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R333 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R334-337 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R338 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R339 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
R340 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R343 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R344 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R345,346 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R347 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
R348,349 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R350 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
R351-353 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R354 247 2006 915 Carbon chip 270ohm 1/16W RM73B--271J
R355,356 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R357,358 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R359 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R360-383 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R384 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R385 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R387 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
R389 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R390 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R391 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
R392,393 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R396 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
R399 247 2008 913 Carbon chip 2kohm 1/16W RM73B--202J
R400 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
R401 247 2004 959 Carbon chip 62ohm 1/16W RM73B--620J
R402,403 247 2004 975 Carbon chip 75ohm 1/16W RM73B--750J
R501,502 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
1U-3444/3444A VIDEO CONVERT P.W.B. UNIT ASS'Y
SEMICONDUCTORS GROUP
IC301 262 2827 902 IC MM74HC4053SJ
IC302 262 2808 002 IC M35015-210SP
IC303 263 0682 003 IC NJM2229S
IC304,305 263 1040 903 IC BU4094BCF
IC306,307 263 1082 903 IC TK15420MTL
IC308,309 262 2013 907 IC BU4053BCF
IC310-312 263 1040 903 IC BU4094BCF
IC313 263 1082 903 IC TK15420MTL
IC314 262 2012 908 IC BU4052BCF
IC315 263 1165 901 IC NJM2274R
IC501-505 263 1082 903 IC TK15420MTL
IC506-509 262 2826 903 IC BU4051BCF
IC510,511 263 1082 903 IC TK15420MTL
IC512,513 262 2013 907 IC BU4053BCF
IC514,515 262 2012 908 IC BU4052BCF
IC516 263 1082 903 IC TK15420MTL
IC603 262 3110 906 IC TC90A69F
IC606,607 262 2012 908 IC BU4052BCF
IC608,609 263 1082 903 IC TK15420MTL
IC611,612 263 1082 903 IC TK15420MTL
IC613 262 2012 908 IC BU4052BCF
IC615 263 1167 006 IC TA8772AN for E2,E1,E1C,EUT
IC616 262 3108 002 IC TA1270BF
IC701,702 263 1082 903 IC TK15420MTL
IC705,706 263 1082 903 IC TK15420MTL
TR301,302 273 0384 900 Transistor 2SC2412K (S)
TR503 271 0238 908 Transistor 2SA1037K (S/R)
TR504,505 269 0082 902 Transistor DTC114EK
TR601,602 273 0426 907 Transistor 2SC2412KLN for E2,E1,E1C,EUT
TR603 271 0238 908 Transistor 2SA1037K (S/R) for E2,E1,E1C,EUT
TR604,605 271 0238 908 Transistor 2SA1037K (S/R)
D301 276 0559 909 Diode DAP202K
D302 276 0740 909 Diode KDS184
D503,504 276 0739 907 Diode KDS181
D601 276 0773 905 Diode RB501V-40
RESISTORS GROUP
R301 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R302 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R303,304 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R305 247 2009 967 Carbon chip 8.2kohm 1/16W RM73B--822J
R306 247 2006 915 Carbon chip 270ohm 1/16W RM73B--271J
