89
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks
1U-3298G TUNER P.W.B. UNIT ASS'Y
(AVR-5803 model only)
OTHER PARTS GROUP
CW048 205 0885 082 4P connector socket (TUC-P) 1
CW056 205 0885 008 5P connector socket (TUC-P) 1
CW070 205 0942 022 7P connector socket (TUC-P) 1
CW080 205 0885 095 8P connector socket (TUC-P) 1
CW094 205 0885 037 9P connector socket (TUC-P) 1
CW109 205 0885 053 10P connector socket (TUC-P) 1
CW872 205 0942 022 7P connector socket (TUC-P) 1
CW944 205 0885 082 4P connector socket (TUC-P) 1
CX051 205 0884 009 5P connector base (TUC-P) 1
CX056 205 0884 009 5P connector base (TUC-P) 1
CX070 205 0943 021 7P connector base (TUC-P) 1
CX088 205 1229 003 8P FJ connector plug 1
CX090 205 0884 038 9P connector base (TUC-P) 1
CX094 205 0884 038 9P connector base (TUC-P) 1
CX106 205 0884 054 10P connector base (TUC-P) 1
CX109 205 0884 054 10P connector base (TUC-P) 1
CX872 205 0943 021 7P connector base (TUC-P) 1
CX944 205 0884 083 4P connector base (TUC-P) 1
CY062 205 0343 061 6P connector base (KR-PH) 1
CY131 205 0375 039 13P connector base (KR-PH) 1
CY871 205 0343 074 7P connector base (KR-PH) 1
FB601,602 235 0106 908 EMI filter (21A05) 2
FB606 235 0106 908 EMI filter (21A05) 1
FB608 235 0106 908 EMI filter (21A05) 1
JK501,502 204 8414 009 2P S-terminal (AU) 2
JK503,504 204 8415 008 3P S-terminal (AU) 2
JK505-507 205 0906 000 1P S-terminal (AU.SW) 3
L301 235 0150 909 Chip inductor 15uH
LQH32MN150J21L 1
L605 235 0150 954 Chip inductor 100uH LQH32MN101J21L 1
L606 235 0150 925 Chip inductor 22uH LQH32MN220J21L 1
L607,608 235 0150 954 Chip inductor 100uH LQH32MN101J21L 2
L612 235 0150 938 Chip inductor 27uH LQH32MN270J21L 1
L703,704 235 0150 938 Chip inductor 27uH LQH32MN270J21L 2
X301 399 0153 006 Crystal 14.32MHz 1
X302 399 0105 009 Ceramic resonator CSB503F2 1
X603 399 0809 004 Crystal 4.43MHz 1
X604 399 0802 001 Crystal 3.58MHz 1
X605 399 0810 006 Ceramic resonator CSB503F30 1
SEMICONDUCTORS GROUP
IC302 263 0439 007 IC LA3401
IC303 263 0891 001 IC LA1265 (S)
IC304 216 0102 008 Front end
IC307 262 2450 900 IC LC72131M-TLM
TR301,302 269 0066 902 Transistor DTC323TK
TR303 269 0054 901 Transistor DTC144EK
TR304 269 0086 908 Transistor DTA114TK
TR305 273 0411 909 Transistor 2SC2996-Y
TR308 269 0083 901 Transistor DTA114EK
TR309 269 0114 906 Transistor RN2402
TR313 269 0083 901 Transistor DTA114EK
D301,302 276 0559 909 Diode DAP202K
D306 276 0559 909 Diode DAP202K
ZD305 276 0644 937 Zener diode MTZJ9.1A
RESISTORS GROUP
R309,310 247 2010 969 Carbon chip 22kohm 1/16W RM73B--223J
R311,312 247 2008 968 Carbon chip 3.3kohm 1/16W RM73B--332J
R313,314 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R315,316 247 2012 941 Carbon chip 120kohm 1/16W RM73B--124J
R317 247 2009 925 Carbon chip 5.6kohm 1/16W RM73B--562J
R318 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R319 247 2010 969 Carbon chip 22kohm 1/16W RM73B--223J
R320 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R321 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R322 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R323 247 2011 971 Carbon chip 62kohm 1/16W RM73B--623J
R324 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R325 247 2008 968 Carbon chip 3.3kohm 1/16W RM73B--332J
R326 247 2005 929 Carbon chip 120ohm 1/16W RM73B--121J
R327 247 2008 942 Carbon chip 2.7kohm 1/16W RM73B--272J
R328 247 2010 943 Carbon chip 18kohm 1/16W RM73B--183J
R329 247 2008 968 Carbon chip 3.3kohm 1/16W RM73B--332J
R330,331 247 2009 983 Carbon chip 10kohm 1/16W RM73B--103J
R332 247 2009 941 Carbon chip 6.8kohm 1/16W RM73B--682J
R333 247 2009 925 Carbon chip 5.6kohm 1/16W RM73B--562J
R334 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R335 247 2011 984 Carbon chip 68kohm 1/16W RM73B--683J
R336 247 2010 927 Carbon chip 15kohm 1/16W RM73B--153J
R337 247 2006 902 Carbon chip 330ohm 1/16W RM73B--331J
R338 247 2007 969 Carbon chip 1.2kohm 1/16W RM73B--122J
R339 247 2009 909 Carbon chip 4.7kohm 1/16W RM73B--472J
R340 247 2006 960 Carbon chip 470ohm 1/16W RM73B--471J
R342 247 2005 987 Carbon chip 220ohm 1/16W RM73B--221J
R343 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R344,345 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R346 247 2009 925 Carbon chip 5.6kohm 1/16W RM73B--562J
R347,348 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
