AVR-5803/AVC-A1SR
PACKING VIEW
203
203
205
201
221
222
222
202
218206
220
204
219
204
PARTS LIST OF PACKING & ACCESSORIES
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
201 504 0192 106 Cabinet sheet 1
202 501 2102 014 Carton case for EU,EC 1
202 501 2102 030 Carton case for E2,E1,E1C,EUT 1
203 501 1950 157 Spacer 2
204 503 1361 108 Cushion Ass'y 1
205 501 2098 005 Pad 1
206 505 8006 019 Envelope 1
207 511 3874 005 Instruction manual (EU) for EU,EC 1
207 511 3910 008 Instruction manual (E2) for E2 1
207 511 3901 004 Instruction manual (E1) for E1,E1C,EUT 1
208 511 3887 005 Instruction manual (EC) for EC 1
209 511 3672 003
Instruction manual (RC-8000)
for EU,EC 1
209 511 3728 009
Instruction manual (RC-871)
for E2 1
209A 511 3808 000
Instruction sheet (RC-8000)
for EU,EC 1
209A 511 3811 000 Instruction sheet (RC-871) for E2 1
209A 511 3810 001 Instruction sheet (RC-871) for E1,E1C,EUT 1
210 511 3687 001
Instruction manual (RC-8001ST)
for EU,EC 1
211 515 0921 005 S.S. list (EX) 1
212 515 0817 009 DEL warranty home for EU 1
213 206 2157 009 AC cord for EU,EC,EUT 1
213 206 2210 001 AC cord for E2,E1 1
213 206 2189 006 AC cord for E1C 1
214 206 2209 009 AC cord (BS3P) for E1 1
215 231 0922 009 Loop antenna for EU,EC 1
216 395 0019 009 FM antenna Ass'y for EU,EC 1
217 529 0079 008 FM ant. adapter for EU,EC 1
218
−
Battery (LR6/AA) 2
219 399 0623 109 Remocon RC-8000 for EU,EC 1
219 399 0623 112 Remocon RC-871 for E2,E1,E1C,EUT 1
220 399 0652 015
Charger base station RC-8001ST
for EU,EC 1
221
−
Bar code label for EU,EC,E2 1
222
−
Control card 1
223 515 0627 105 DCI warranty home for EC 1
224 513 9111 001 Color label (gold) Gold model 2
225 513 3518 066 Carton label (C) for E1C 1
226 513 3549 064 Carton label (T) for EUT 1
Note: The symbol in the column "Remarks" indicate the following destinations.
EU: U.S.A. model (AVR-5803) E1: Asia model
EC: Canada model (AVR-5803) E1C: China model
E2: Europe model EUT: Taiwan R.O.C. model
To Next Page
