Denon AVR-5803 Service Manual

71
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
1U-3404/3404A/3404E/3404F PRE P.W.B. UNIT ASS'Y
SEMICONDUCTORS GROUP
IC101,102 268 0073 905 IC ICP-N15
IC103 263 0809 006 IC NJM7805FA (S)
IC104 263 0554 005 IC NJM7905FA
IC105,106 268 0073 905 IC ICP-N15
IC107 263 0809 006 IC NJM7805FA (S)
IC201 263 1035 002 IC PQ30RV11
IC202 268 0073 905 IC ICP-N15
IC501 263 0986 000 IC NJM7820FA (S)
IC502 263 0801 004 IC NJM7812FA (S) for EU,EC
IC509 263 1163 000 IC KIA78R09PI
TR101 271 0117 906 Transistor 2SA1020 (Y)
TR102 273 0212 904 Transistor 2SC2655 (Y)
TR103 273 0303 910 Transistor 2SC1740S (S)
TR104 271 0192 905 Transistor 2SA933S (S)
TR105 272 0115 011 Transistor 2SB1186A (E)
TR106 269 0020 906 Transistor DTC114ES (10K-10K)
TR201 273 0303 910 Transistor 2SC1740S (S)
TR202 269 0040 902 Transistor DTC144ES (47K-47K)
TR203 273 0303 910 Transistor 2SC1740S (S)
TR204 269 0020 906 Transistor DTC114ES (10K-10K)
TR205 271 0192 905 Transistor 2SA933S (S)
TR206 273 0303 910 Transistor 2SC1740S (S)
TR301,302 273 0445 001 Transistor 2SC4495
TR303,304 271 0192 905 Transistor 2SA933S (S)
TR512 269 0020 906 Transistor DTC114ES (10K-10K)
D101,102 276 0432 903 Diode 1SS270A
D103,104 276 0704 903 Diode 1SR35-400A
D108-111 276 0704 903 Diode 1SR35-400A
D201,202 276 0704 903 Diode 1SR35-400A
D203 276 0432 903 Diode 1SS270A
D204-207 276 0704 903 Diode 1SR35-400A
D208,209 276 0432 903 Diode 1SS270A
D507 276 0432 903 Diode 1SS270A
D508-510 276 0681 000 Diode FMG-22S
D511,512 276 0682 009 Diode FMG-22R
D513,514 276 0681 000 Diode FMG-22S
D515,516 276 0682 009 Diode FMG-22R
D517,518 276 0704 903 Diode 1SR35-400A
ZD101 276 0484 919 Zener diode HZS33-2
ZD201 276 0637 902 Zener diode MTZJ6.2A
ZD202 276 0645 907 Zener diode MTZJ18A
RESISTORS GROUP
R208 241 2379 987 Carbon film 1kohm 1/4W (NB) RD14B2E102JNBS
R211,212 243 2091 009 Winding 33ohm 10W RW78A4A330J= (UL)
R213 242 2009 001 Composition 2.2Mohm 1/2W RC05GF2H225K (UL)
for EU,EC
R214 245 2365 980 Metal film 390ohm 1/4W RN14K2E391F
R215 245 2367 920 Metal film 1.5kohm 1/4W RN14K2E152F
CAPACITORS GROUP
C101 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C102-109 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C110 254 4403 721 Electrolytic 2200uF/25V CE04W1E222M (SMG)
C111 254 4540 710 Electrolytic 470uF/63V
CE04W1J471M (SMG/RE3)
C112 254 4403 734 Electrolytic 4700uF/25V CE04W1E472M (SMG)
C113 254 4403 721 Electrolytic 2200uF/25V CE04W1E222M (SMG)
C114,115 256 1058 971 Metallized 0.1uF/50V CF93A1H104J (JL)
C116,117 256 1042 903 Metallized 0.1uF/250V CF93A2E104K
C118,119 256 1058 971 Metallized 0.1uF/50V CF93A1H104J (JL)
C120 256 1042 903 Metallized 0.1uF/250V CF93A2E104K
C201 254 4524 930 Electrolytic 0.47uF/50V CE04W1HR47M (SMG/RE3)
C202 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C203 254 4403 734 Electrolytic 4700uF/25V CE04W1E472M (SMG)
C204 255 1265 936 Mylar film 0.01uF/50V CQ93M1H103J (B)
C205 254 4525 900 Electrolytic 33uF/50V CE04W1H330M (SMG/RE3)
C206,207 254 4524 972 Electrolytic 4.7uF/50V CE04W1H4R7M (SMG/RE3)
C208 256 1058 971 Metallized 0.1uF/50V CF93A1H104J (JL)
C209 253 8022 707 Ceramic 0.01uF/250V (AC) CK45F2EAC103M
C210 254 4524 927 Electrolytic 0.33uF/50V CE04W1HR33M (SMG/RE3)
C301,302 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C501 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C503,504 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
for EU,EC
C505,506 254 4523 708 Electrolytic 3300uF/35V CE04W1V332M (SMG/RE3)
C529-536 254 4504 714 Electrolytic 3300uF/35V CE04W1V332M (ASF)
C537-540 254 4452 714 Electrolytic 2200uF/16V CE04W1C222M (ASF)
C541-547 254 4612 703 Electrolytic 10000uF/20V CE04W--103M (SMG)
C548,549 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C550 254 4523 708 Electrolytic 3300uF/35V CE04W1V332M (SMG/RE3)
C551-553 256 1042 903 Metallized 0.1uF/250V CF93A2E104K
C554,555 256 1058 971 Metallized 0.1uF/50V CF93A1H104J (JL)
C556 254 4523 708 Electrolytic 3300uF/35V CE04W1V332M (SMG/RE3)
C559-561 256 1058 971 Metallized 0.1uF/50V CF93A1H104J (JL)
